caseih mx245
 | 2006 - 2007
Magnum-Serie Feldbau-Traktor | 2006 - 2007 | Magnum Serie | Ackerschlepper |
|---|---|---|---|---|
2006 - 2007 | ||||
Magnum Serie | ||||
Ackerschlepper | ||||
2006 - 2007 | |
|---|---|
Magnum Serie | |
Ackerschlepper |
Produktion | |
|---|---|
Hersteller | Case IH |
Ackerschlepper | |
Gebaut in Racine, Wisconsin, USA | |
CaseIH MX245 Motor | |
|---|---|
CNH 8,3-Liter-6-Zylinder-Diesel | |
Motordetails ...  |
CaseIH MX245 Getriebe | |
|---|---|
18-Gang-Leistungsschaltung | |
19-Gang-Lastschaltgetriebe - Überlast | |
23-Gang Kriecher | |
Getriebe Details ...  |
CaseIH MX245 Power | |
|---|---|
Motor | 248 PS
184,9 kW |
Zwillingskupplung (angegeben) | 200 PS
149,1 kW |
Anhängevorrichtung (geprüft) | 172,67 PS
128,8 kW |
Kraftübertragung (geprüft) | 203,97 PS
152,1 kW |
Leistungsprüfung Details ...  | |
Mechanisch | |
|---|---|
Allradantrieb | |
Servolenkung | |
Unabhängige hydraulische Nassscheibenbremsen | |
Kabinenstandard. |
Fotos | |
|---|---|
 | |
CaseIH MX245 Fotos...  |
Kapazität | |
|---|---|
Kraftstoff | 180 Gallonen
681,3 L |
Hydrauliksystem | 45,5 Gallonen
172,2 Liter |
Hydraulik | |
|---|---|
Typ | druckkompensiert |
Kapazität | 45,5 Gallonen
172,2 Liter |
Ventile | 3 bis 5 |
Gesamtstrom | 38,6 gpm
146,1 lpm |
| 58 gpmOptional
219,5 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | III |
Hecklift | 13960 lbs
6332 kg |
| 15970 PfundOptOptional
7243 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | unabhängig |
Heck-PTO Typ | 540/1000 |
Abmessungen & Reifen | |
|---|---|
Radstand | 118,3 Zoll
300 cm |
Gewicht | 21185 Pfund
9609 kg |
Vollständige Abmessungen und Reifen ...  | |
Elektrisch | |
|---|---|
Boden | negativ |
Ladeampere | 150 |
| 175 OptOptional |
Batterie CCA | 2000 |
Batteriespannung | 12 |
