caseih steiger 550 quadtrac
 | 2011 -
Gelenkter Raupentraktor | 2011 - | Gelenkter Raupentraktor |
|---|---|---|---|
2011 - | |||
Gelenkter Raupentraktor | |||
2011 - | |
|---|---|
Gelenkter Raupentraktor |
Produktion | |
|---|---|
Hersteller | Case IH |
Gelenkter Raupentraktor | |
Gebaut in Fargo, North Dakota, USA | |
Varianten | |
|---|---|
550 | Radschlepper |
550QT | Raupen-Traktor |
CaseIH Steiger 550 Quadtrac Motor | |
|---|---|
Iveco 12,9L 6-Zylinder Diesel | |
Kraftstofftank | 470 Gallonen
1779,0 L |
Abgasfluid (DEF) | 64 Gallonen
242,2 L |
Motordetails ...  | |
CaseIH Steiger 550 Quadtrac Getriebe | |
|---|---|
16-Gang-Leistungswechsel | |
Getriebe Details ...  |
CaseIH Steiger 550 Quadtrac Power | |
|---|---|
Motor | 550 PS
410,1 kW |
Zwillingskupplung (angegeben) | 475 PS
354,2 kW |
Anhängevorrichtung (geprüft) | 434,20 PS
323,8 kW |
Kraftübertragung (geprüft) | 535,77 PS
399,5 kW |
Leistungsprüfung Details ...  | |
Mechanisch | |
|---|---|
Fahren | Gelenkkettenfahrzeug |
Standardkabine des Vermessers. | |
Fotos | |
|---|---|
 | |
CaseIH Steiger 550 Quadtrac Fotos...  |
Hydraulik | |
|---|---|
Typ | geschlossenes Mittelzentrums-Druckflusskompensiert (PFC) |
Heckventile | 4 bis 8 |
Pumpenleistung | 35 gpm
132,5 lpm |
Gesamtstrom | 42 gpm
159,0 lpm |
| 56 gpm (Hoher Fluss)
212,0 lpm |
| 113 gpm (Twin Flow)
427,7 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | 4N |
Hecklift | 19.728 lbs
8948 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | unabhängig |
Heck-PTO Typ | 1000 (1-3/4) |
Abmessungen & Ketten | |
|---|---|
Radstand | 154 Zoll
391 cm |
Gewicht | 53.804 lbs
24405 kg |
Ketten | |
Vollständige Abmessungen und Spurweite ...  | |
Elektrisch | |
|---|---|
Boden | negativ |
Ladesystem | Lichtmaschine |
Ladeampere | 200 |
Batterien | 2 |
Batterie CCA | 1000 |
Batteriespannung | 12 |
Referenzen | |
|---|---|
 | |
Steiger-Schlepper-Serie veröffentlicht im Jahr 2011, von CaseIH |
