challenger 1046
![]() | 2017 - 2021
1000er Serie Feldbau-Traktor | 2017 - 2021 | 1000er Serie | Ackerschlepper |
|---|---|---|---|---|
2017 - 2021 | ||||
1000er Serie | ||||
Ackerschlepper | ||||
2017 - 2021 | |
|---|---|
1000er Serie | |
Ackerschlepper |
Produktion | |
|---|---|
Hersteller | Challenger (Teil von AGCO) |
Ackerschlepper | |
Gebaut in Marktoberdorf, Deutschland | |
Der ursprüngliche Preis betrug 418.820 Dollar im Jahr 2019 | |
Challenger 1046 Motor | |
|---|---|
MAN 12,4L 6-Zylinder-Diesel | |
Kraftstofftank | 211 Gallonen
798,6 L |
Abgasfluid (DEF) | 22 gal
83,3 L |
Motordetails ... | |
Getriebe Challenger 1046 | |
|---|---|
stufenlos getriebe | |
Getriebe Details ... |
Challenger 1046 Leistung | |
|---|---|
Motor (grobe Leistung) | 476 PS
355,0 kW |
Zwillingskupplung (angegeben) | 421 PS
313,9 kW |
Anhängevorrichtung (geprüft) | 382,7 PS
285,4 kW |
Kraftübertragung (geprüft) | 443,0 PS
330,3 kW |
Leistungsprüfung Details ... | |
Mechanisch | |
|---|---|
Allradantrieb | |
Servolenkung | |
Hydraulische Scheibenbremsen | |
Kabine Standard mit Klimaanlage. Auto-Guide; AccuField Command; AgControl |
Hydraulik | |
|---|---|
Typ | lastabhängig |
Ventile | bis zu 6 |
Pumpenleistung | 58 gpm
219,5 lpm |
| 113,5 lpm*Optional, mit zusätzlicher 55,5-GPM-Pumpe.
429,6 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | IV/IVN |
Heckhub (an den Enden) | 18631 Pfund
8451 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | unabhängig |
Heck-PTO Typ | 1000/1000E |
Abmessungen & Reifen | |
|---|---|
Radstand | 130 Zoll
330 cm |
Gewicht | 32734 Pfund
14848 kg |
Vorderreifen | 650/65R38 |
Hinterreifen | 750/75R46 |
Vollständige Abmessungen und Reifen ... | |
Elektrisch | |
|---|---|
Boden | negativ |
Ladesystem | Lichtmaschine |
Ladeampere | 320 *Zwei 160A Lichtmaschinen*. |
Batterien | 2 |
Batteriespannung | 12 |
Referenzen | |
|---|---|
![]() | |
1000er-Serie veröffentlicht im Jahr 2016 von Caterpillar |
