chamberlain 3380
 | 1975 - 1985 | 1975 - 1985 |
|---|---|---|
1975 - 1985 | ||
1975 - 1985 |
|---|
Produktion | |
|---|---|
Hersteller | John Deere |
In Welshpool, Australien gebaut | |
Gesamt gebaut | 1.521 |
Varianten | |
|---|---|
3380A | gebaut 1975-1983 |
3380B | gebaut 1983-1985 |
John Deere 3380 Motor | |
|---|---|
John Deere 3,9-Liter 4-Zylinder Diesel | |
Motordetails ...  |
John Deere 3380 Getriebe | |
|---|---|
12-Gang | |
Getriebe Details ...  |
John Deere 3380 Power | |
|---|---|
Motor | 73 PS
54,4 kW |
Zwillingskupplung (angegeben) | 68 PS
50,7 kW |
Mechanisch | |
|---|---|
Zweiradantrieb | |
Servolenkung | |
Limousine mit Heizung und Klimaanlage. |
Fotos | |
|---|---|
 | |
John Deere 3380 Fotos...  |
Hydraulik | |
|---|---|
Typ | offen mittig |
Ventile | 1 |
Pumpenleistung | 15,8 gpm
59,8 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | II |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | live |
Heck-PTO Typ | 540 |
Motordrehzahl | 540@1970 |
Abmessungen & Reifen | |
|---|---|
Gewicht | 10141 lbs
4599 kg |
Vorderreifen | 9.00-16 |
Hinterreifen | 23.1-26 |
Vollständige Abmessungen und Reifen ...  | |
Referenzen | |
|---|---|
 | |
Technisches Jahrbuch veröffentlicht 1977 von Power Farming | |
Technisches Jahrbuch veröffentlicht 1981 von Power Farming |
