cub cadet lawn tractors 1210
![]() | 1985 - 1989
Gartentraktor | 1985 - 1989 | Gartenfahrzeug |
|---|---|---|---|
1985 - 1989 | |||
Gartenfahrzeug | |||
1985 - 1989 | |
|---|---|
Gartenfahrzeug |
Produktion | |
|---|---|
Hersteller | Cub Cadet (Teil von MTD) |
Gartenfahrzeug | |
Gebaut in Brownsville, Tennessee, USA | |
Varianten | |
|---|---|
1204 | Zahnradantrieb |
1210 | hydrostatisch |
1211 | Hydro mit hydraulischer Hubvorrichtung |
Cub Cadet 1210 Motor | |
|---|---|
12PS Kohler 476cc 1-Zylinder Benzin | |
Kraftstofftank | 4 Gallonen
15,1 Liter |
Motordetails ... | |
Cub Cadet 1210 Getriebe | |
|---|---|
hydrostatisch | |
Getriebe Details ... |
Mechanisch | |
|---|---|
Zweiradantrieb | |
Manuelle Lenkung | |
Mechanische Scheibenbremsen | |
Offene Bedienstation. |
Fotos | |
|---|---|
![]() | |
Cub Cadet 1210 Fotos... |
Traktoranbausystem | |
|---|---|
Hinterer Typ | 0 Optionell |
Typ | Schleppheck OptOptional |
Kraftentnahme (PTO) | |
|---|---|
Frontkraftheber | unabhängig |
Kupplung | elektrisch |
Abmessungen & Reifen | |
|---|---|
Radstand | 44 Zoll
111 cm |
Gewicht | 692 lbs
313 kg |
Vorderreifen | 16x6.50-8 |
Hinterreifen | 23x10,50-12 |
Vollständige Abmessungen und Reifen ... | |
Cub Cadet 1210 Anhänge | |
|---|---|
38" Mittelaufbau-Mähdeck | |
44" Mähdeck, mittig montiert | |
50" Mittelaufbau-Mähdeck | |
Schneeschleuder | |
Messer | |
Befestigungsdetails ... |
1210 Seriennummern | |
|---|---|
Standort: | Seriennummernschild an der linken Seite des Traktorrahmens, oberhalb der Fußstütze. |
1985 | 737625 |
1986 | 747225 |
1987 | 756300 |
1988 | 767352 |
1989 | 779097 |
FAQ: Wie liest man eine Seriennummerntabelle? | |
Elektrisch | |
|---|---|
Boden | negativ |
Ladesystem | Lichtmaschine |
Ladeampere | 15 |
Batteriespannung | 12 |
Referenzen | |
|---|---|
![]() | |
Bedienungsanleitung Traktoren 1210 - 1710 - 1711 - 1712 veröffentlicht im Jahr 1985, von Cub Cadet | |
Haustraktoren veröffentlicht 1985 von Cub Cadet | |
Gartenschlepper veröffentlicht im Jahr 1987 von Cub Cadet | |
Cub Cadet Gartentraktoren veröffentlicht im Jahr 1988 | |
Cub Cadet Garten-Traktoren veröffentlicht im Jahr 1989 |
