kubota m4030
![]() | 1986 - 1989
Traktor der M30-Serie | 1986 - 1989 | M30-Serie | Bauwagen |
|---|---|---|---|---|
1986 - 1989 | ||||
M30-Serie | ||||
Bauwagen | ||||
1986 - 1989 | |
|---|---|
M30-Serie | |
Bauwagen |
Produktion | |
|---|---|
Hersteller | Kubota |
Bauwagen | |
Gebaut in Japan | |
Varianten | |
|---|---|
M4030DT | 4x4 |
M4030F | Standard |
M4030L | niedriges Profil |
M4030SU | spezieller Nutzungszweck |
Kubota M4030 Motor | |
|---|---|
Kubota 2,6L 6-Zylinder-Diesel | |
Motordetails ... |
Kubota M4030 Getriebe | |
|---|---|
8-Gang | |
Getriebe Details ... |
Kubota M4030 Leistung | |
|---|---|
Motor | 48 PS
35,8 kW |
Zwillingskupplung (angegeben) | 43 PS
32,1 kW |
Anhängevorrichtung (geprüft) | 36,53 PS
20,1 kW |
Kraftübertragung (geprüft) | 44,05 PS
32,8 kW |
Leistungsprüfung Details ... | |
Mechanisch | |
|---|---|
Zweirad- oder Vierradantrieb | |
Differentialsperre | Standard |
Servolenkung | |
Differential mechanische Mehrscheibenbremsen im Ölbad | |
Zwei-Säulen-ROPS. | |
Kapazität | |
|---|---|
Kraftstoff | 16,9 Gallonen
64,0 L |
Hydrauliksystem | 12,7 gal (2WD)
48,1 L |
| 14,9 Gallonen (4WD)
56,4 L |
Hydraulik | |
|---|---|
Typ | offen mittig |
Kapazität | 12,7 gal (2WD)
48,1 L |
| 14,9 Gallonen (4WD)
56,4 L |
Druck | 2630 psi
181,3 bar |
Ventile | 1 |
Gesamtstrom | 11 gpm
41,6 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | II/I |
Heckhub (an den Enden) | 3.968 lbs
1799 kg |
Heckhub (bei 24"/610mm) | 3.307 lbs
1500 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | unabhängig |
Heck-PTO Typ | 540 |
Motordrehzahl | 540@2194 |
Abmessungen & Reifen | |
|---|---|
Radstand 2WD | 78,7 Zoll
199 cm |
4x4 Radstand | 79,1 Zoll
200 cm |
Gewicht | 4078 bis 4806 Pfund |
Vorderreifen | 6,00-16 |
Hinterreifen | 13.6-28 (2WD) |
Vollständige Abmessungen und Reifen ... | |
Kubota M4030 Anhängungen | |
|---|---|
Frontlader | |
Befestigungsdetails ... |
Referenzen | |
|---|---|
![]() | |
Frontlader veröffentlicht 1988 von Kubota | |
Frontlader B, L und M-Serie veröffentlicht 1994 von Kubota* | |
Produktkatalog veröffentlicht 1990, von Kubota | |
M30-Serie - Nutzen/Landwirtschaft/Niedriges Profil veröffentlicht im Jahr 1986 von Kubota | |
M30-Serie - Utility-Agri/Low Profile/Narrow/Mudder veröffentlicht 1991 von Kubota | |
*Veröffentlichung enthält bekannte Fehler. |
