kubota m6060
![]() | 2013 -
M60 Serien Nutztraktor | 2013 - | M60-Serie | Bauwagen |
|---|---|---|---|---|
2013 - | ||||
M60-Serie | ||||
Bauwagen | ||||
2013 - | |
|---|---|
M60-Serie | |
Bauwagen |
Produktion | |
|---|---|
Hersteller | Kubota |
Bauwagen | |
Varianten | |
|---|---|
M6060HF | 2WD ROPS |
M6060HFC | 2WD Kabine |
M6060HD | 4WD ROPS |
M6060HDC | 4WD Kabine |
Kubota M6060 Motor | |
|---|---|
Kubota 3.3L 4-Zylinder Diesel | |
ROPS Kraftstofftank | 18,5 Gallonen
70,0 Liter |
Kraftstofftank für Fahrerkabine | 23,8 Gal
90,1 L |
Motordetails ... | |
Kubota M6060 Getriebe | |
|---|---|
8-Gang-Lastschaltgetriebe | |
Getriebe Details ... |
Kubota M6060 Power | |
|---|---|
Motor (Netto) | 63,5 PS
47,4 kW |
Zwillingskupplung (angegeben) | 56 PS
41,8 kW |
Mechanisch | |
|---|---|
Zweirad- oder Vierradantrieb | |
Lenkung | hydrostatische Kraft |
Nassbremsen | |
Zwei-Pfosten-ROPS, klappbar. Optionale Ultra Grand Cab mit Klimaanlage. Optionale Luftfederungssitz und AM/FM/CD/MP3-Soundsystem. | |
Fotos | |
|---|---|
![]() | |
Kubota M6060 Fotos... |
Hydraulik | |
|---|---|
Ventile | 1 bis 3 |
Pumpenleistung | 11 gpm
41,6 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | II/I |
Steuerung | Positionsregelung und Zugkraftregelung des oberen Zugglieds |
Heckhub (bei 24"/610mm) | 3307 lbs
1500 kg |
Hintere Anbauarme | teleskopische untere Anhängerkupplungsenden |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | unabhängig |
Kupplung | elektrohydraulisch |
Heck-PTO Typ | 540 (1.375 |
| 540/540E (1.375) |
Abmessungen & Reifen | |
|---|---|
Radstand 2WD | 84,4 Zoll
214 cm |
4x4 Radstand | 83,1 Zoll
211 cm |
Gewicht | 5005 bis 5358 Pfund |
Vorderreifen | 7,5-16 |
Hinterreifen | 16.9-28 (2WD) |
Vollständige Abmessungen und Reifen ... | |
Kubota M6060 Anbaugeräte | |
|---|---|
Frontlader | |
Befestigungsdetails ... |
Elektrisch | |
|---|---|
Boden | negativ |
Ladesystem | Lichtmaschine |
ROPS Ladespannung | 45 |
Ladekabel-Stromstärke | 60 |
Optionale Ladeamps | 100 |
Batteriespannung | 12 |
Referenzen | |
|---|---|
![]() | |
M6060/M7060 veröffentlicht im Jahr 2012 von Kubota |
