landini globus 75
 | 1999 - 2001
Globus Serie Nutzfahrzeug-Traktor | 1999 - 2001 | Globus-Serie | Bauwagen |
|---|---|---|---|---|
1999 - 2001 | ||||
Globus-Serie | ||||
Bauwagen | ||||
1999 - 2001 | |
|---|---|
Globus-Serie | |
Bauwagen |
Produktion | |
|---|---|
Hersteller | Landini |
Bauwagen | |
Varianten | |
|---|---|
Globus 75 GT | Niedrigprofil |
Landini Globus 75 Motor | |
|---|---|
Perkins 4,2L 4-Zylinder-Diesel | |
Kraftstofftank | 17,7 Liter
67,0 Liter |
| 9 Gallonen (Zusatztank)
34,1 L |
Motordetails ...  | |
Landini Globus 75 Getriebe | |
|---|---|
25-Gang | |
50-Gang | |
Getriebe Details ...  |
Landini Globus 75 Power | |
|---|---|
Motor | 74 PS
55,2 kW |
Mechanisch | |
|---|---|
Fahren | 4x2 2WD |
| 4x4 MFWD 4WD (optional) |
Differentialsperre | mechanisch |
Lenkung | hydrostatische Kraft |
Hydraulische Scheibenbremsen | |
Anhängerbremsen | hydraulisch optional |
Fotos | |
|---|---|
 | |
Landini Globus 75 Fotos...  |
Hydraulik | |
|---|---|
Druck | 2600 psi
179,3 bar |
Ventile | 2 oder 3 |
SCV-Durchfluss | 14,2 gpm
53,7 lpm |
Gesamtstrom | 22,2 gpm
84,0 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | 2 |
Steuerung | Position und Zugkontrolle |
Hecklift | 4.600 lbs
2086 kg |
| 7.500 lbs (optional)
3402 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | unabhängig |
Kupplung | elektrohydraulische, befeuchtete Scheibenkupplung |
Heck-PTO Typ | 540/1000/Boden |
| 540/750/Boden |
Abmessungen & Reifen | |
|---|---|
4x4 Radstand | 85 Zoll
215 cm |
GT Radstand | 85,3 Zoll
216 cm |
Gewicht | 6.724 lbs
3050 kg |
Vorderreifen | 7,50-16 |
Hinterreifen | 14.9R30 (2WD) |
Vollständige Abmessungen und Reifen ...  | |
Elektrisch | |
|---|---|
Boden | negativ |
Batteriespannung | 12 |
