ls s3010
![]() | 2009 - 2011
Kompakter Vielzwecktractor | 2009 - 2011 | Kompakt-Bau-Traktor |
|---|---|---|---|
2009 - 2011 | |||
Kompakt-Bau-Traktor | |||
2009 - 2011 | |
|---|---|
Kompakt-Bau-Traktor |
Produktion | |
|---|---|
Hersteller | LS |
Kompakt-Bau-Traktor | |
LS S3010 Motor | |
|---|---|
Mitsubishi 1,5L 4-Zylinder-Diesel | |
Kraftstofftank | 8,4 Gal
31,8 L |
Motordetails ... | |
LS S3010 Getriebe | |
|---|---|
8-Gang Synchro-Shuttle | |
Getriebe Details ... |
LS S3010 Power | |
|---|---|
Motor (grobe Leistung) | 28,5 PS
15,7 kW |
Zwillingskupplung (angegeben) | 24 PS
17,9 kW |
Mechanisch | |
|---|---|
Allradantrieb | |
Lenkung | hydrostatische Kraft |
Nassbremsen | |
Zwei-Säulen-ROPS. | |
Fotos | |
|---|---|
![]() | |
LS S3010 Fotos... |
Hydraulik | |
|---|---|
Ventile | 0 bis 2 |
Pumpenleistung | 6,2 gpm
23,5 lpm |
Gesamtstrom | 10,3 Gallonen pro Minute
39,0 Liter pro Minute |
Lenkungsfluss | 4,1 gpm
15,5 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | Ich |
Steuerung | Positionsregelung |
Hecklift | 1433 lbs
650 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | live |
Heck-PTO Typ | 540 (1,375) |
Abmessungen & Reifen | |
|---|---|
Radstand | 66 Zoll
167 cm |
Gewicht | 2769 Pfund
1256 kg |
Vorderreifen | 7-14 |
Hinterreifen | 11,5-24 |
Vollständige Abmessungen und Reifen ... | |
LS S3010 Anhänge | |
|---|---|
Frontlader | |
Bagger | |
Befestigungsdetails ... |
Elektrisch | |
|---|---|
Boden | negativ |
Ladesystem | Lichtmaschine |
Ladeampere | 50 |
Batteriespannung | 12 |
