massey ferguson 1505
![]() | 1974 - 1977
Allradtraktor | 1974 - 1977 | Vierradantriebs-Traktor (4WD) |
|---|---|---|---|
1974 - 1977 | |||
Vierradantriebs-Traktor (4WD) | |||
1974 - 1977 | |
|---|---|
Vierradantriebs-Traktor (4WD) |
Produktion | |
|---|---|
Hersteller | Massey Ferguson |
Vierradantriebs-Traktor (4WD) | |
Gebaut in Des Moines, Iowa, USA | |
Der ursprüngliche Preis betrug 36.000 Dollar im Jahr 1977 | |
Massey Ferguson 1505 Motor | |
|---|---|
Caterpillar 10,4L 8-Zylinder-Diesel | |
Motordetails ... |
Massey Ferguson 1505 Getriebe | |
|---|---|
12-Gang | |
Getriebe Details ... |
Massey Ferguson 1505 Power | |
|---|---|
Motor | 185 PS
138,0 kW |
Anhängevorrichtung (geprüft) | 146,65 PS
81,1 kW |
Kraftübertragung (geprüft) | 174,46 PS
130,1 kW |
Leistungsprüfung Details ... | |
Mechanisch | |
|---|---|
Allradantrieb | |
Lenkung | hydrostatische Kraft |
Hydraulische innenbelüftete Schuhbremsen | |
Standardkabine. Optionale Heizung und Klimaanlage. | |
Fotos | |
|---|---|
![]() | |
Massey Ferguson 1505 Fotos... |
Hydraulik | |
|---|---|
Ventile | 2 oder 3 |
Pumpenleistung | 25 gpm
94,6 lpm |
Gesamtstrom | 50 GPM
189,2 LPM |
Traktoranbausystem | |
|---|---|
Hinterer Typ | optional |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | unabhängig OptOptional |
Heck-PTO Typ | 1000 |
Abmessungen & Reifen | |
|---|---|
Radstand | 120 Zoll
304 cm |
Gewicht | 17.960 lbs
8146 kg |
Vorderreifen | 23,1-30 |
Hinterreifen | 23,1-30 |
Vollständige Abmessungen und Reifen ... | |
1505 Seriennummern | |
|---|---|
Standort: | Platte am Armaturenbrett. |
1974 | 9C003184 |
1975 | 9C004227 |
1976 | 9C006806 |
1977 | 9C007858 |
FAQ: Wie liest man eine Seriennummerntabelle? | |
Elektrisch | |
|---|---|
Boden | negativ |
Batteriespannung | 12 |
Referenzen | |
|---|---|
![]() | |
Vollständiger Leitfaden für landwirtschaftliche Maschinen, veröffentlicht im Jahr 1976 von Massey Ferguson |
