mtd lawn tractors 390
 | 1966 - 1982
Baujahr 1966-19711973-1982
Rasenmäher-Traktor | 1966 - 1982 | Baujahr 1966-19711973-1982 | Rasen-Traktor |
|---|---|---|---|---|
1966 - 1982 | ||||
Baujahr 1966-19711973-1982 | ||||
Rasen-Traktor | ||||
1966 - 1982 | |
|---|---|
Baujahr 1966-19711973-1982 | |
Rasen-Traktor |
Produktion | |
|---|---|
Hersteller | MTD |
Rasen-Traktor | |
Originalpreis war 300 $ im Jahr 1967 | |
MTD 390 Motor | |
|---|---|
6PS Briggs & Stratton 1-Zylinder-Benzinmotor | |
Motordetails ...  |
MTD 390 Getriebe | |
|---|---|
3-Gang-Getriebe | |
Getriebe Details ...  |
Mechanisch | |
|---|---|
Zweiradantrieb | |
Manuelle Lenkung | |
Offene Bedienstation. |
Fotos | |
|---|---|
 | |
MTD 390 Fotos...  |
Abmessungen & Reifen | |
|---|---|
Gewicht | 280 lbs
127 kg |
Vorderreifen | 10,25-3,50 |
Hinterreifen | 12,50-4,50 |
Vollständige Abmessungen und Reifen ...  | |
MTD 390 Anhänge | |
|---|---|
25-Zoll mittiger Mähdeck | |
Befestigungsdetails ...  |
390 Seriennummern | |
|---|---|
1966 | 136-390 (Modellcode) |
1967 | 137-390 (Modellcode) |
1968 | 138-390 (Modellcode) |
1969 | 139-390 (Modellcode) |
1970 | 130-390 (Modellcode) |
1971 | 131-390 (Modellcode) |
FAQ: Wie liest man eine Seriennummerntabelle? | |
Referenzen | |
|---|---|
 | |
Betriebs- und Wartungsanleitungen 132-380, 132-385, 132-390, 132-395 (770-3543) veröffentlicht im Jahr 1972 | |
MTD Teile Explosionszeichnungen (770-9101) veröffentlicht im Jahr 1974 | |
Die '68er Aktionslinie, veröffentlicht 1968, von MTD |
