new holland t5070
 | 2008 - 2013
T5000 Serie Nutztraktor | 2008 - 2013 | T5000-Serie | Bauwagen |
|---|---|---|---|---|
2008 - 2013 | ||||
T5000-Serie | ||||
Bauwagen | ||||
2008 - 2013 | |
|---|---|
T5000-Serie | |
Bauwagen |
Produktion | |
|---|---|
Hersteller | New Holland |
Bauwagen | |
Gebaut in Jesi, Italien | |
New Holland T5070 Motor | |
|---|---|
New Holland 4,5L 4-Zylinder-Diesel | |
Kraftstofftank | 33,5 Gallonen
126,8 L |
Motordetails ...  | |
New Holland T5070 Getriebe | |
|---|---|
12-Gang-Lastschaltgetriebe | |
24-Gang-Power-Shuttle | |
Getriebe Details ...  |
New Holland T5070 Power | |
|---|---|
Motor (grobe Leistung) | 115 PS
85,8 kW |
Zwillingskupplung (angegeben) | 96 PS
71,6 kW |
Anhängevorrichtung (geprüft) | 77,8 PS
58,0 kW |
Kraftübertragung (geprüft) | 103,0 PS
76,8 kW |
Leistungsprüfung Details ...  | |
Mechanisch | |
|---|---|
Fahren | 4x2 2WD |
| 4x4 MFWD 4WD (optional) |
Differentialsperre | mechanische Heckstandard |
| optional elektrohydraulische Vorder- und Hinterachse |
Servolenkung | |
Hydraulische Scheibenbremsen | |
Flache Plattform mit ROPS. Kabine optional mit Heizung und Klimaanlage. | |
Fotos | |
|---|---|
 | |
Neue Holland T5070 Fotos...  |
Hydraulik | |
|---|---|
Typ | offen mittig |
Druck | 2.871 psi
198,0 bar |
Heckventile | 2 bis 3 (offenes oder geschlossenes Mittelstück) |
Mittelventile | 0 bis 2 |
Pumpenleistung | 16.1 Gallonen pro Minute
60.9 Liter pro Minute |
Lenkungsfluss | 10,4 gpm
39,4 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | II |
Steuerung | mechanische Zugkraftregelung |
Heckhub (bei 24"/610mm) | 5.475 lbs
2483 kg |
| 6.805 lbsOptional
3086 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | unabhängig |
Kupplung | mechanisch |
| elektrohydraulisch Optional |
Heck-PTO Typ | 540/1000 (1,375) |
Motordrehzahl | 540@2199 |
| 1000@2261 |
Abmessungen & Reifen | |
|---|---|
Radstand | 92,5 Zoll
234 cm |
Vollständige Abmessungen und Reifen ...  | |
New Holland T5070 Anhänge | |
|---|---|
Frontlader | |
Befestigungsdetails ...  |
Elektrisch | |
|---|---|
Boden | negativ |
Ladesystem | Lichtmaschine |
Ladeampere | 120 |
Batterie CCA | 960 |
Batteriespannung | 12 |
