new holland ts6020
 | 2010 - 2012
TS6000-Serie Reihenkulturtraktor | 2010 - 2012 | TS6000-Serie | Ackerschlepper |
|---|---|---|---|---|
2010 - 2012 | ||||
TS6000-Serie | ||||
Ackerschlepper | ||||
2010 - 2012 | |
|---|---|
TS6000-Serie | |
Ackerschlepper |
Produktion | |
|---|---|
Hersteller | New Holland |
Ackerschlepper | |
Originalpreis | 46.704 $ (2012 8-Gang Kabine 2WD) |
38.549 $ (2012 8-Gang ROPS 2WD) | |
53.450 $ (2012 8-Gang-Kabine Allrad) | |
45.295 $ (2012 8-Gang ROPS 2WD ) | |
New Holland TS6020 Motor | |
|---|---|
FPT 4,5L 4-Zylinder-Diesel | |
Kraftstofftank | 39 Gallonen
147,6 L |
Motordetails ...  | |
New Holland TS6020 Getriebe | |
|---|---|
8-Gang-Konstantgang | |
12-Gang-Konstantverzahnung mit Kriechgang | |
16-Gang | |
24-Gang | |
Getriebe Details ...  |
New Holland TS6020 Power | |
|---|---|
Motor (grobe Leistung) | 110 PS
82,0 kW |
Zwillingskupplung (angegeben) | 90 PS
67,1 kW |
Kraftübertragung (geprüft) | 96,32 PS
71,8 kW |
Leistungsprüfung Details ...  | |
Mechanisch | |
|---|---|
Fahren | 4x2 2WD |
| 4x4 MFWD 4WD (optional) |
Lenkung | hydrostatische Kraft |
Nassbremsen | |
Klappbarer ROPS mit zwei Pfosten. Optionale Kabine mit Klimaanlage. | |
Hydraulik | |
|---|---|
Typ | offen mittig |
Ventile | 2 |
Pumpenleistung | 13 gpm
49,2 lpm |
| 22 gpm (optional)
83,3 lpm |
Lenkungsfluss | 7 gpm
26,5 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | 2 |
Steuerung | mechanische Zugmaul-Zugkraftregelung |
Heckhub (bei 24"/610mm) | 3.600 lbs
1632 kg |
| 5.400 lbs (optionaler Hubzylinder)
2449 kg |
| 7.200 lbs (optional dual lift cylinders)
3265 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | unabhängig |
Heck-PTO Typ | 540/1000 |
Abmessungen & Reifen | |
|---|---|
Gewicht | 7617 bis 9088 Pfund |
Vollständige Abmessungen und Reifen ...  | |
Elektrisch | |
|---|---|
Boden | negativ |
Ladesystem | Lichtmaschine |
Ladeampere | 120 |
Batterie CCA | 950 |
Batteriespannung | 12 |
