satoh s370
![]() | 1977 - 1984
Kompakter Nutzfahrzeug-Traktor | 1977 - 1984 | Kompakt-Bau-Traktor |
|---|---|---|---|
1977 - 1984 | |||
Kompakt-Bau-Traktor | |||
1977 - 1984 | |
|---|---|
Kompakt-Bau-Traktor |
Produktion | |
|---|---|
Hersteller | Satoh |
Kompakt-Bau-Traktor | |
Varianten | |
|---|---|
S-370 | 2WD |
S-370D | 4x4 |
Satoh S370 Motor | |
|---|---|
Mitsubishi 0,7L 2-Zylinder-Diesel | |
Kraftstofftank | 3,3 gal
12,5 L |
Motordetails ... | |
Satoh S370 Getriebe | |
|---|---|
6-Gang-Getriebe, nicht synchronisiert | |
Getriebe Details ... |
Satoh S370 Leistung | |
|---|---|
Motor (grobe Leistung) | 15 PS
11,2 kW |
Motor (Netto) | 13 PS
9,7 kW |
Zwillingskupplung (angegeben) | 12,2 PS
9,1 kW |
Mechanisch | |
|---|---|
Fahren | 4x2 2WD |
| 4x4 MFWD 4WD (S-370D) |
Differentialsperre | Fußpedal |
Lenkung | manuell |
Mechanische innenliegende selbststellende Schuhbremsen | |
Offene Bedienstation. | |
Fotos | |
|---|---|
![]() | |
Satoh S370 Fotos... |
Hydraulik | |
|---|---|
Druck | 1920 psi
132,4 bar |
Gesamtstrom | 3,84 gpm
14,5 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | 0 |
Heckhub (an den Enden) | 1.274 lbs
577 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | Getriebe |
Heck-PTO Typ | 540/1000 |
Abmessungen & Reifen | |
|---|---|
Radstand | 48,23 Zoll (2WD)
122 cm |
| 49,80 Zoll (4WD)
126 cm |
Gewicht | 1035,3 bis 1180,6 Pfund |
Vorderreifen | 4.00-9 |
Hinterreifen | 8-16 (2WD) |
Vollständige Abmessungen und Reifen ... | |
Satoh S370 Anhänge | |
|---|---|
Frontlader | |
Befestigungsdetails ... |
Elektrisch | |
|---|---|
Boden | negativ |
Ladesystem | Lichtmaschine |
Ladeampere | 26.5 |
Batteriespannung | 12 |
