satoh s470
 | 1979 - 1984
Kompakter Nutzfahrzeugtraktor | 1979 - 1984 | Kompakt-Bau-Traktor |
|---|---|---|---|
1979 - 1984 | |||
Kompakt-Bau-Traktor | |||
1979 - 1984 | |
|---|---|
Kompakt-Bau-Traktor |
Produktion | |
|---|---|
Hersteller | Satoh |
Kompakt-Bau-Traktor | |
Gebaut in Japan | |
Varianten | |
|---|---|
S470D | 4x4 |
Satoh S470 Motor | |
|---|---|
Mitsubishi 0,8L 3-Zylinder-Diesel | |
Kraftstofftank | 4 Gallonen
15,1 Liter |
Motordetails ...  | |
Satoh S470 Getriebe | |
|---|---|
6-Gang-Getriebe | |
Getriebe Details ...  |
Satoh S470 Leistung | |
|---|---|
Motor | 18,5 PS
13,8 kW |
Zwillingskupplung (angegeben) | 15 PS
11,2 kW |
Mechanisch | |
|---|---|
Fahren | 4x2 2WD |
| 4x4 MFWD 4WD (S470D) |
Lenkung | manuell |
Trommelbremsen | |
Offene Bedienstation. | |
Fotos | |
|---|---|
 | |
Satoh S470 Fotos...  |
Hydraulik | |
|---|---|
Pumpenleistung | 3,5 gpm
13,2 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | Ich |
Steuerung | nicht-positionale Steuerung |
Heckhub (an den Enden) | 1100 lbs
498 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO Typ | 540 (1,375) |
Abmessungen & Reifen | |
|---|---|
Gewicht | 1157 bis 1268 Pfund |
Vorderreifen | 4,5-10 |
Hinterreifen | 8-18 (2WD) |
Vollständige Abmessungen und Reifen ...  | |
Elektrisch | |
|---|---|
Boden | negativ |
Batteriespannung | 12 |
Batterie Ah | 45 |
