simplicity lawn tractors 7013
![]() | 1976 - 1977
7000er-Serie
Gartenfahrzeug | 1976 - 1977 | 7000er Serie | Gartenfahrzeug |
---|---|---|---|---|
1976 - 1977 | ||||
7000er Serie | ||||
Gartenfahrzeug |
1976 - 1977 | |
---|---|
7000er Serie | |
Gartenfahrzeug |
Produktion | |
---|---|
Hersteller | Einfachheit |
Gartenfahrzeug |
Simplicity 7013 Motor | |
---|---|
13 PS Briggs & Stratton 494cc 1-Zylinder-Benzinmotor | |
Kraftstofftank | 3 Gallonen
11,4 Liter |
Motordetails ... ![]() |
Simplicity 7013 Getriebe | |
---|---|
4-Gang-Getriebe | |
Getriebe Details ... ![]() |
Mechanisch | |
---|---|
Zweiradantrieb | |
Manuelle Lenkung | |
Mechanische Bandbremsen | |
Offene Bedienstation. |
Fotos | |
---|---|
![]() | |
Simplicity 7013 Fotos... ![]() |
Kraftentnahme (PTO) | |
---|---|
Mittel PTO | unabhängig |
Kupplung | mechanisch |
Abmessungen & Reifen | |
---|---|
Radstand | 48,1 Zoll
122 cm |
Gewicht | 814 lbs
369 kg |
Vorderreifen | 16-6,50x8 |
Hinterreifen | 23-8,50x12 |
Vollständige Abmessungen und Reifen ... ![]() |
Simplicity 7013 Zubehör | |
---|---|
42-Zoll Mittelaufbau-Mähdeck | |
48-Zoll Mittelaufbau-Mähdeck | |
Schneeschleuder | |
Messer | |
Befestigungsdetails ... ![]() |
Elektrisch | |
---|---|
Boden | negativ |
Batteriespannung | 12 |
Referenzen | |
---|---|
![]() | |
Gartenfahrzeug Modell 7013 veröffentlicht im Jahr 1963 von Simplicity | |
Garten- und Rasenpflegegeräte, veröffentlicht 1976 von Simplicity |
