tym t330
 | 2002 - 2009
Kompakter Vielzwecktraktor | 2002 - 2009 | Kompakt-Bau-Traktor |
|---|---|---|---|
2002 - 2009 | |||
Kompakt-Bau-Traktor | |||
2002 - 2009 | |
|---|---|
Kompakt-Bau-Traktor |
Produktion | |
|---|---|
Hersteller | TYM |
Kompakt-Bau-Traktor | |
Hergestellt in Südkorea | |
TYM T330 Motor | |
|---|---|
Kubota 1,5L 3-Zylinder-Diesel | |
Motordetails ...  |
TYM T330 Getriebe | |
|---|---|
12-Gang-Sync-Shuttle | |
hydrostatisch | |
Getriebe Details ...  |
TYM T330 Power | |
|---|---|
Motor | 31 PS
23,1 kW |
Zwillingskupplung (angegeben) | 26,5 PS
19,8 kW |
Mechanisch | |
|---|---|
Allradantrieb | |
Differentialsperre | mechanische Hinterachse |
Servolenkung | |
Nassbremsen | |
Zwei-Säulen-ROPS. | |
Fotos | |
|---|---|
 | |
TYM T330 Fotos...  |
Kapazität | |
|---|---|
Kraftstoff | 8,2 gal
31,0 L |
Hydrauliksystem | 8,5 gal
32,2 L |
Hydraulik | |
|---|---|
Typ | offen mittig |
Kapazität | 8,5 gal
32,2 L |
Ventile | 2 |
Pumpenleistung | 6,3 gpm
23,8 lpm |
Gesamtstrom | 9,7 gpm
36,7 lpm |
| 10.85 gpm (hydro)
41.1 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | Ich |
Heckhub (an den Enden) | 2078 lbs
942 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | unabhängig |
Heck-PTO Typ | 540 (1,375) |
Motordrehzahl | 540@2541 |
Abmessungen & Reifen | |
|---|---|
Radstand | 64 Zoll
162 cm |
Gewicht | 3000 lbs
1360 kg |
Vorderreifen | 7-16 |
Hinterreifen | 11,5-24 |
Vollständige Abmessungen und Reifen ...  | |
Elektrisch | |
|---|---|
Boden | negativ |
Ladesystem | Lichtmaschine |
Ladeampere | 50 |
Batteriespannung | 12 |
Referenzen | |
|---|---|
 | |
Bedienungsanleitung für T290/T300/T330 (1350-912-002-0) veröffentlicht im Jahr 2005 |
