volvo 2200
 | 1978 - 1981
2200 Serie Nutztraktor | 1978 - 1981 | 2200er Serie | Bauwagen |
|---|---|---|---|---|
1978 - 1981 | ||||
2200er Serie | ||||
Bauwagen | ||||
1978 - 1981 | |
|---|---|
2200er Serie | |
Bauwagen |
Produktion | |
|---|---|
Hersteller | Volvo |
Bauwagen | |
Gesamt gebaut | 1819 |
Varianten | |
|---|---|
2200 | 2WD |
2204 | 4x4 |
Volvo 2200 Motor | |
|---|---|
Volvo 3,9L 4-Zylinder-Diesel | |
Kraftstofftank | 23.2 Gallonen
87.8 L |
Motordetails ...  | |
Volvo 2200 Getriebe | |
|---|---|
8-Gang-Synchromesch | |
16-Gang-Doppelgeschwindigkeit-Powershift | |
Getriebe Details ...  |
Volvo 2200 Leistung | |
|---|---|
Motor | 56 PS
41,8 kW |
Zwillingskupplung (angegeben) | 46 PS
34,3 kW |
Mechanisch | |
|---|---|
Zweiradantrieb | |
Lenkung | hydrostatische Kraft |
Hydraulische Scheibenbremsen | |
Volvo BM Kabine Standard mit Heizung. | |
Fotos | |
|---|---|
 | |
Volvo 2200 Fotos...  |
Hydraulik | |
|---|---|
Druck | 2495 psi
172,0 bar |
Ventile | 2 |
Pumpenleistung | 11,9 gpm
45,0 lpm |
Traktoranbausystem | |
|---|---|
Hinterer Typ | II |
Steuerung | Position und Zugkontrolle |
Hecklift | 4079 lbs
1850 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | unabhängig |
Heck-PTO Typ | 540 (1,375) |
Motordrehzahl | 540@1940 |
Abmessungen & Reifen | |
|---|---|
Radstand | 85,43 Zoll
216 cm |
Gewicht | 6493 lbs
2945 kg |
Vorderreifen | 7,50-16 |
Hinterreifen | 13,6-38 |
Vollständige Abmessungen und Reifen ...  | |
Elektrisch | |
|---|---|
Boden | negativ |
Ladesystem | Lichtmaschine |
Ladeampere | 35 |
Batterien | 2 |
Batteriespannung | 12 |
Batterie Ah | 140 |
Referenzen | |
|---|---|
 | |
Volvo BM 2200 veröffentlicht 1978 | |
Volvo BM 2200 veröffentlicht im Jahr 1979 |
