volvo t810
 | 1969 - 1978
Reihenanbau-Traktor | 1969 - 1978 | Ackerschlepper |
|---|---|---|---|
1969 - 1978 | |||
Ackerschlepper | |||
1969 - 1978 | |
|---|---|
Ackerschlepper |
Produktion | |
|---|---|
Hersteller | Volvo |
Ackerschlepper | |
Gebaut in Eskilstuna, Schweden | |
Gesamt gebaut | 3550 |
Originalpreis | 40.000 $ (1978) |
Varianten | |
|---|---|
T810 | 2WD |
T814 | 4x4 |
Volvo T810 Motoren | |
|---|---|
Volvo 5.1L 6-Zylinder-Diesel | |
Volvo 5.5L 6-Zylinder-Diesel | |
Kraftstofftank | 39,6 Gallonen
149,9 L |
Motordetails ...  | |
Volvo T810 Getriebe | |
|---|---|
8-Gang | |
Getriebe Details ...  |
Volvo T810 Power | |
|---|---|
Motor | 133 PS
99,2 kW |
Mechanisch | |
|---|---|
Zweiradantrieb | |
Differentialsperre | Standard |
Lenkung | hydrostatische Kraft |
Scheibenbremsen | |
Kabine optional mit Heizung | |
Fotos | |
|---|---|
 | |
Volvo T810 Fotos...  |
Hydraulik | |
|---|---|
Typ | Trac-Trol |
Druck | 2275 psi
156,9 bar |
Ventile | 2 |
Pumpenleistung | 7,9 GPM
29,9 LPM |
| 11,9 Gallonen pro Minute (optional)
45,0 Liter pro Minute |
Traktoranbausystem | |
|---|---|
Hecklift | 5.200 lbs
2358 kg |
| 6.170 lbs (optional)
2798 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO Typ | 1000 |
| 540/1000 |
Abmessungen & Reifen | |
|---|---|
Radstand | 106 Zoll
269 cm |
Gewicht | 11.800 Pfund
5352 kg |
Vorderreifen | 11.00-16 |
Hinterreifen | 18,4-38 |
Vollständige Abmessungen und Reifen ...  | |
Referenzen | |
|---|---|
 | |
Volvo BM T 500 veröffentlicht im Jahr 1971 |
