zetor 5511
 | 1968 - 1972 | 1968 - 1972 |
|---|---|---|
1968 - 1972 | ||
1968 - 1972 |
|---|
Produktion | |
|---|---|
Hersteller | Zetor |
Gebaut in Brünn, Tschechoslowakei | |
Varianten | |
|---|---|
5511 | 2WD offen |
5545 | 4WD offen |
5611 | 2WD Kabine |
Zetor 5511 Motor | |
|---|---|
Zetor 3.1L 4-Zylinder-Diesel | |
Motordetails ...  |
Zetor 5511 Getriebe | |
|---|---|
10-Gang-Schaltung | |
Getriebe Details ...  |
Zetor 5511 Power | |
|---|---|
Motor | 56 PS
41,8 kW |
Anhängerkupplung (angegeben) | 48 PS
35,8 kW |
Zwillingskupplung (angegeben) | 53,9 PS
40,2 kW |
Mechanisch | |
|---|---|
Zweiradantrieb | |
Endantriebe | Sperrrad |
Differentialsperre | mechanische Hinterachse |
Lenkung | manuell |
Lenkung | Leistung (5611) |
Hydraulische Trommelbremsen | |
Offene Bedienstation. | |
Fotos | |
|---|---|
 | |
Zetor 5511 Fotos...  |
Hydraulik | |
|---|---|
Typ | offen mittig |
Druck | 2134 psi
147,1 bar |
Ventile | 1 |
Traktoranbausystem | |
|---|---|
Hinterer Typ | II/I |
Steuerung | Position und Zugkontrolle |
Heckhub (an den Enden) | 3080 Pfund
1397 kg |
Kraftentnahme (PTO) | |
|---|---|
Heck-PTO | live |
Heck-PTO Typ | 540 (1,375) |
Motordrehzahl | 540@2000 |
Abmessungen & Reifen | |
|---|---|
Radstand | 89 Zoll
226 cm |
Gewicht | 4950 lbs
2245 kg |
Vorderreifen | 6.00-18 |
Hinterreifen | 13-28 |
Vollständige Abmessungen und Reifen ...  | |
Referenzen | |
|---|---|
 | |
5511 - 5545 - 5611 veröffentlicht von Zetor* | |
*Veröffentlichung enthält bekannte Fehler. |
