john deere lawn tractors 111h
 | 1982 - 1984
100 Lawn SeriesLawn tractor | 1982 - 1984 | 100 Lawn Series | Lawn tractor |
|---|---|---|---|---|
1982 - 1984 | ||||
100 Lawn Series | ||||
Lawn tractor | ||||
1982 - 1984 | |
|---|---|
100 Lawn Series | |
Lawn tractor |
Production | |
|---|---|
Manufacturer | John Deere |
Lawn tractor | |
Built in Horicon, Wisconsin, USA | |
Original price was $2,649 in 1983 | |
Variants | |
|---|---|
111 | gear transmission |
111H | hydrostatic transmission |
John Deere 111H Engine | |
|---|---|
11HP Briggs & Stratton 399cc 1-cyl gasoline | |
Fuel tank | 2.5 gal
9.5 L |
Engine details ...  | |
John Deere 111H Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Photos | |
|---|---|
 | |
John Deere 111H photos...  |
Power Take-off (PTO) | |
|---|---|
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 44.7 inches
113 cm |
Weight | 470 lbs
213 kg |
Front tire | 15x6.00-6 |
Rear tire | 18x8.50-8 |
Full dimensions and tires ...  | |
John Deere 111H attachments | |
|---|---|
38" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ...  |
111H Serial Numbers | |
|---|---|
Location: | Serial number decal on the dashboard below the steering column. |
1982 | M0111H190001 |
1983 | M0111H257001 |
1984 | M0111H285001 |
Final | M0111H315000 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 3 |
Battery volts | 12 |
References | |
|---|---|
 | |
Operator's Manual 111 Hydrostatic Lawn Tractor (OM-M84079) published in 1981 | |
Lawn Tractors and Riding Mowers published in 1982, by John Deere | |
Lawn Tractors & Riding Mowers 1983 published by John Deere | |
Consumer Products Price List published in 1983, by John Deere | |
Grounds Care Equipment Purchasing Guide published in 1983, by John Deere |
