kubota m135gx
 | 2012 -
Grand X SeriesRow-Crop tractor | 2012 - | Grand X Series | Row-Crop tractor |
|---|---|---|---|---|
2012 - | ||||
Grand X Series | ||||
Row-Crop tractor | ||||
2012 - | |
|---|---|
Grand X Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Kubota |
Row-Crop tractor | |
Original price was $81,752 in 2014 | |
Kubota M135GX Engine | |
|---|---|
Kubota 6.1L 4-cyl diesel | |
Fuel tank | 50.2 gal
190.0 L |
Engine details ...  | |
Kubota M135GX Transmissions | |
|---|---|
24-speed eight-speed power shift | |
32-speed | |
Transmission details ...  |
Kubota M135GX Power | |
|---|---|
Engine | 135 hp
100.7 kW |
PTO (claimed) | 118 hp
88.0 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | electro-hydraulic front and rear |
Steering | hydrostatic power |
Hydraulic wet disc brakes | |
Grand X Cab standard with air-conditioning. | |
Photos | |
|---|---|
 | |
Kubota M135GX photos...  |
Hydraulics | |
|---|---|
Valves | 2 to 4 |
Pump flow | 18.7 gpm
70.8 lpm |
Steering flow | 16 gpm
60.6 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | electronic lower-link draft control |
Rear lift (at 24"/610mm) | 6834 lbs
3099 kg |
| 9447 lbs (optional)
4285 kg |
Rear Arms | telescopic lower link ends |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | hydraulic wet disc |
Rear PTO Type | 540/1000 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 105.9 inches
268 cm |
Weight | 10373 lbs
4705 kg |
Front tire | 14.9R24 |
Rear tire | 18.4R38 |
Full dimensions and tires ...  | |
Kubota M135GX attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
M135GX Serial Number Location | |
|---|---|
 | |
Right side of tractor frame, above the front axle. |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 80 |
Battery CCA | 1090 |
Battery volts | 12 |
Battery AH | 160 |
