kubota lawn tractors zg23
 | 2003 - 2007
ZG SeriesZero-turn mower | 2003 - 2007 | ZG Series | Zero-turn mower |
|---|---|---|---|---|
2003 - 2007 | ||||
ZG Series | ||||
Zero-turn mower | ||||
2003 - 2007 | |
|---|---|
ZG Series | |
Zero-turn mower |
Production | |
|---|---|
Manufacturer | Kubota |
Zero-turn mower | |
Kubota ZG23 Engine | |
|---|---|
23HP Kubota 673cc 2-cyl gasoline | |
Fuel tank | 6.1 gal
23.1 L |
Engine details ...  | |
Kubota ZG23 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | differential power |
Wet disc brakes | |
Two-post folding ROPS. | |
Photos | |
|---|---|
 | |
Kubota ZG23 photos...  |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Mid PTO Type | Kubota 10-tooth |
Dimensions & Tires | |
|---|---|
Wheelbase | 46.7 inches
118 cm |
Weight | 1102 lbs
499 kg |
Front tire | 13x5.0-6 |
Rear tire | 23x10.5-12 |
Full dimensions and tires ...  | |
Kubota ZG23 attachments | |
|---|---|
54" mid-mount mower deck | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery CCA | 285 |
Battery volts | 12 |
Battery Group | U1L-9 |
References | |
|---|---|
 | |
Zero-Turn Mower ZG published in 2003, by Kubota |
