tym t233
 | 2006 - 2011
Tráctor de utilidad compacta | 2006 - 2011 | Tractor de utilidad compacta |
|---|---|---|---|
2006 - 2011 | |||
Tractor de utilidad compacta | |||
2006 - 2011 | |
|---|---|
Tractor de utilidad compacta |
Producción | |
|---|---|
Fabricante | TYM |
Tractor de utilidad compacta | |
Motor TYM T233 | |
|---|---|
Mitsubishi 1.1L 3 cilindros diésel | |
Tanque de combustible | 6,6 gal
25,0 L |
Detalles del motor ...  | |
Transmisión TYM T233 | |
|---|---|
hidrostática | |
Detalles de la transmisión ...  |
TYM T233 Potencia | |
|---|---|
Motor (bruto) | 23 hp
17,2 kW |
PTO (declarado) | 19,5 cv
14,5 kW |
Mecánico | |
|---|---|
Tracción en las cuatro ruedas | |
Dirección | potencia hidrostática |
Frenos de disco húmedos | |
ROPS de dos postes. | |
Fotos | |
|---|---|
 | |
Fotos de TYM T233...  |
Hidráulicos | |
|---|---|
Tipo | bomba de engranajes |
Válvulas | 1 |
Caudal de la bomba | 5.0 gpm
18.9 lpm |
Flujo total | 7,6 gpm
28,8 lpm |
Enganche de tractor | |
|---|---|
Tipo Trasero | Yo |
Elevación trasera (en los extremos) | 1,653 lbs
749 kg |
Elevación trasera (a 24"/610mm) | 1,213 lbs
550 kg |
Toma de fuerza (PTO) | |
|---|---|
Toma de fuerza trasera | independiente |
Embrague | electro-hidráulico |
Tipo de PTO trasero | 540 (1,375) |
PTO Intermedio | independiente |
Tipo de PTO intermedio | 2000 |
Dimensiones y Neumáticos | |
|---|---|
Distancia entre ejes | 58,3 pulgadas
148 cm |
Peso | 1,654 lbs
750 kg |
Neumático delantero | 6-12 |
Neumático trasero | 9.5-20 |
Dimensiones y neumáticos completos...  | |
implementos TYM T233 | |
|---|---|
cargador frontal | |
Detalles de acoplamiento...  |
Eléctrica | |
|---|---|
Suelo | negativo |
Sistema de carga | alternador |
Amperaje de carga | 50 |
Voltaje de la batería | 12 |
Referencias | |
|---|---|
 | |
Manual del operador Carga LT200 (LTS16-01200) publicado en 2005 |
