agco gt55
 | 2004 - 2007
GT SeriesUtility tractor | 2004 - 2007 | GT Series | Utility tractor |
|---|---|---|---|---|
2004 - 2007 | ||||
GT Series | ||||
Utility tractor | ||||
2004 - 2007 | |
|---|---|
GT Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | AGCO |
Utility tractor | |
Built in Italy | |
AGCO GT55 Engine | |
|---|---|
SAME Deutz-Fahr 3.0L 3-cyl diesel | |
Fuel tank | 23.7 gal
89.7 L |
Engine details ...  | |
AGCO GT55 Transmission | |
|---|---|
16-speed | |
Transmission details ...  |
AGCO GT55 Power | |
|---|---|
Engine | 56 hp
41.8 kW |
PTO (claimed) | 53 hp
39.5 kW |
PTO (tested) | 58.89 hp
43.9 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Final drives | planetary |
Differential lock | mechanical rear |
Power steering | |
Wet disc brakes | |
Two-post folding ROPS. Cab optional with air-conditioning. | |
Photos | |
|---|---|
No photos of the AGCO GT55 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics | |
|---|---|
Type | open center |
Pump flow | 14 gpm
53.0 lpm |
Total flow | 22.7 gpm
85.9 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Rear lift (at 24"/610mm) | 3520 lbs
1596 kg |
Rear Arms | fixed |
| telescopic OptOptional |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@1967 |
| 1000@2043 |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 82.9 inches
210 cm |
4WD Wheelbase | 80.9 inches
205 cm |
Weight | 4982 to 6225 pounds |
Full dimensions and tires ...  | |
AGCO GT55 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
GT Series - Rugged Comfort published in 2003, by AGCO | |
GT Series published in 2003, by AGCO | |
GT Series published in 2004, by AGCO |
 | |
|---|---|
