allis chalmers 6080

1980 - 1985

6000 Series

Row-Crop tractor

6000 Series

Row-Crop tractor

Manufacturer

Allis Chalmers

Row-Crop tractor

Built in West Allis, Wisconsin, USA

Total built

6,698

Original price

$30,000 (1985)

Allis Chalmers 3.3L 4-cyl diesel

12-speed synchronized

Drawbar (tested)

70.50 hp 52.6 kW

PTO (tested)

83.66 hp 62.4 kW

Drive

4x2 2WD



4x4 MFWD 4WD (optional)

Steering

hydrostatic power

Differential hydraulic wet disc brakes

Four-post ROPS canopy. Optional cab and air-conditoning.

Fuel

32 gal 121.1 L

Rear diff.

37 qts 35.0 L

Type

open center

Valves

2

Pump flow

11.4 gpm 43.1 lpm

Total flow

19 gpm 71.9 lpm

Rear Type

II

Rear lift (at 24"/610mm)

4,500 lbs 2041 kg

Rear PTO

independent

Rear PTO Type

540/1000

Wheelbase

96 inches (2WD) 243 cm



95.3 inches (4WD) 242 cm

Weight

6,500 lbs 2948 kg

Front tire

7.50-16

Rear tire

18.4-34

engine adapter housing, right side

1980

1001

1981

1152

1982

3002

1983

4567

1984

5780

1985

6853

Final

7698

FAQ: How to read a serial number table.

Charging system

alternator

Charging amps

72

Batteries

1



2 (optional)

Battery volts

12

6080 - 6060 published in 1982, by Allis Chalmers
