allis chalmers 7000
 | 1975 - 1979
7000 SeriesRow-Crop tractor | 1975 - 1979 | 7000 Series | Row-Crop tractor |
|---|---|---|---|---|
1975 - 1979 | ||||
7000 Series | ||||
Row-Crop tractor | ||||
1975 - 1979 | |
|---|---|
7000 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Allis Chalmers |
Row-Crop tractor | |
Built in West Allis, Wisconsin, USA | |
Total built | 7,264 |
Original price | $24,860 |
The Allis model 7000 had two versions, the early maroon (or brown) chassis and the later black chassis. The switch occured in 1978, with serial number 8000 as the first black chassis tractor. The black-chassis featured a new transmission design and new cab. | |
Allis Chalmers 7000 Engine | |
|---|---|
Allis Chalmers 4.9L 6-cyl diesel | |
Engine details ...  |
Allis Chalmers 7000 Transmission | |
|---|---|
12-speed partial power shift | |
Transmission details ...  |
Allis Chalmers 7000 Power | |
|---|---|
Drawbar (claimed) | 89 hp
66.4 kW |
PTO (claimed) | 106 hp
79.0 kW |
Drawbar (tested) | 89.46 hp
66.7 kW |
PTO (tested) | 106.44 hp
79.4 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two-wheel drive | |
Power steering | |
Differential dry disc brakes | |
Acousta-Cab optional. Acousta-Cab II on black chassis models. |
Photos | |
|---|---|
 | |
Allis Chalmers 7000 photos...  |
Capacity | |
|---|---|
Fuel | 37 gal
140.0 L |
Hydraulic system | 7 gal
26.5 L |
Rear diff. | 32 qts
30.3 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 7 gal
26.5 L |
Valves | 1 |
Pump flow | 21 gpm
79.5 lpm |
Total flow | 25 gpm
94.6 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 1000 |
| 540/1000 |
Engine RPM | 540@2200 |
| 1000@2200 |
Dimensions & Tires | |
|---|---|
Wheelbase | 106 inches
269 cm |
Weight | 9350 to 9550 pounds |
Front tire | 10.00-16 |
Rear tire | 18.4x38 |
Full dimensions and tires ...  | |
Allis Chalmers 7000 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
7000 Serial Numbers | |
|---|---|
Location: | Serial number stamped on the right rear of the Allis 7000 differential housing, near the right lift cylinder. |
1975 | 1001 |
1976 | 1648 |
1977 | 5036 |
1978 | 6373 |
1979 | 8963 |
Final | 9503 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Batteries | 1 |
| 2 OptOptional |
Battery volts | 12 |
Battery AH | 95 |
References | |
|---|---|
 | |
Loaders - picking up where the others leave off published in 1979, by Allis Chalmers | |
7000 - Looks, act, sounds like its bigger brothers. published in 1975, by Allis Chalmers | |
7000 - Turbocharged Workhorse That Keeps Its Cool published in 1978, by Allis Chalmers | |
Operator's Manual 7000 (260623) published in 1975 |
