allis chalmers 7580

1976 - 1981

Four-wheel Drive (4WD) tractor

Four-wheel Drive (4WD) tractor

Manufacturer

Allis Chalmers

Four-wheel Drive (4WD) tractor

Built in West Allis, Wisconsin, USA

Total built

1610

Original price

$63,084

Allis Chalmers 7.0L 6-cyl diesel

Fuel tank

170 gal 643.5 L

20-speed partial power shift

Drawbar (claimed)

153 hp 114.1 kW

PTO (claimed)

186 hp 138.7 kW

Drawbar (tested)

153.70 hp 114.6 kW

PTO (tested)

186.35 hp 139.0 kW

Four-wheel drive

Steering

hydrostatic power

Hydraulic wet discs brakes

Acousta cab standard with heat and air-conditioning. Optional radio and 8 track tape player.

Type

closed center

Valves

3 to 4

Pump flow

23 gpm 87.1 lpm

Total flow

74.9 gpm 283.5 lpm

Rear Type

III

Rear PTO

independent

Rear PTO Type

1000

Wheelbase

126 inches 320 cm

Weight

23100 to 23510 pounds

Front tire

20.8x38

Rear tire

20.8x38

Location:

Front frame, rear left side

1976

1001

1977

1288

1978

1605

1979

2218

1980

2486

1981

2717

Final

3018

FAQ: How to read a serial number table.

Charging system

alternator

Batteries

4

Battery volts

12

Four-wheel drives - mammoth size... published in 1978, by Allis Chalmers

7580 - The beat built to eat acres, not fuel. published in 1977, by Allis Chalmers
