belarus 1770
 | 1985 - 1997
Four-wheel Drive (4WD) tractorXTZ built | 1985 - 1997 | Four-wheel Drive (4WD) tractor | XTZ built |
|---|---|---|---|---|
1985 - 1997 | ||||
Four-wheel Drive (4WD) tractor | ||||
XTZ built | ||||
1985 - 1997 | |
|---|---|
Four-wheel Drive (4WD) tractor | |
XTZ built |
Production | |
|---|---|
Distributor | Belarus |
Manufacturer | XTZ |
Four-wheel Drive (4WD) tractor | |
Built in Kharkiv, Ukraine | |
Original price was $44,000 in 1997 | |
Belarus 1770 Engine | |
|---|---|
Belarus 9.2L 6-cyl diesel | |
Engine details ...  |
Belarus 1770 Transmission | |
|---|---|
12-speed four-speed power shift | |
Transmission details ...  |
Belarus 1770 Power | |
|---|---|
Engine | 185 hp
138.0 kW |
Drawbar (claimed) | 151 hp
112.6 kW |
PTO (claimed) | 171 hp
127.5 kW |
Drawbar (tested) | 148.11 hp
110.4 kW |
PTO (tested) | 167.6 hp
125.0 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Four-wheel drive | |
Steering | articulated hydraulic power |
Pneumatic shoe brakes | |
Cab standard. | |
Photos | |
|---|---|
 | |
Belarus 1770 photos...  |
Capacity | |
|---|---|
Fuel | 83.2 gal
314.9 L |
Hydraulic system | 10.25 gal
38.8 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 10.25 gal
38.8 L |
Pressure | 2275 psi
156.9 bar |
Valves | 2 |
Pump flow | 28.2 gpm
106.7 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift | 12480 lbs
5660 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Engine RPM | 540@2025 |
| 1000@2050 |
Dimensions & Tires | |
|---|---|
Wheelbase | 112.6 inches
286 cm |
Weight | 19585 lbs
8883 kg |
Front tire | 23.1-26 |
Rear tire | 23.1-26 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Model 1770 published in 1988, by Belarus |
