branson 4815r
 | 2015 - 2023
15 SeriesCompact Utility tractor | 2015 - 2023 | 15 Series | Compact Utility tractor |
|---|---|---|---|---|
2015 - 2023 | ||||
15 Series | ||||
Compact Utility tractor | ||||
2015 - 2023 | |
|---|---|
15 Series | |
Compact Utility tractor |
Production | |
|---|---|
Manufacturer | Branson (a part of TYM) |
Compact Utility tractor | |
Variants | |
|---|---|
4815R | shuttle |
4815H | hydrostatic |
4815CH | cab |
Branson 4815R Engine | |
|---|---|
Kukje 2.3L 4-cyl diesel | |
Engine details ...  |
Branson 4815R Transmission | |
|---|---|
12-speed shuttle | |
Transmission details ...  |
Branson 4815R Power | |
|---|---|
Engine | 47 hp
35.0 kW |
PTO (claimed) | 40 hp
29.8 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Two-post folding ROPS. |
Photos | |
|---|---|
No photos of the Branson 4815R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics | |
|---|---|
Pump flow | 8.7 gpm
32.9 lpm |
Steering flow | 4.7 gpm
17.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position control |
Rear lift (at ends) | 3306 lbs
1499 kg |
Rear lift (at 24"/610mm) | 2420 lbs
1097 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Dimensions & Tires | |
|---|---|
Front tire | 7-16 |
Rear tire | 12.4-24 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
15 Series published in 2019, by Branson |
 | |
|---|---|
