caseih 1896
 | 1985 - 1989
96 SeriesRow-Crop tractor | 1985 - 1989 | 96 Series | Row-Crop tractor |
|---|---|---|---|---|
1985 - 1989 | ||||
96 Series | ||||
Row-Crop tractor | ||||
1985 - 1989 | |
|---|---|
96 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | CaseIH |
Row-Crop tractor | |
Built in Racine, Wisconsin, USA | |
Original price was $35,000 in 1989 | |
While usually listed as only a CaseIH mode, the 1896 was built for nearly a year in Case white before become a red CaseIH tractor. | |
CaseIH 1896 Engine | |
|---|---|
CDC 5.9L 6-cyl diesel | |
Engine details ...  |
CaseIH 1896 Transmission | |
|---|---|
12-speed three-speed power shift | |
Transmission details ...  |
CaseIH 1896 Power | |
|---|---|
PTO (claimed) | 95 hp
70.8 kW |
Drawbar (tested) | 84.51 hp
63.0 kW |
PTO (tested) | 95.92 hp
71.5 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | electric rear |
Power steering | |
Differential hydraulic wet disc brakes | |
Two-post folding ROPS. Cab optional with air-conditioning. | |
Photos | |
|---|---|
 | |
CaseIH 1896 photos...  |
Capacity | |
|---|---|
Fuel | 65 gal
246.0 L |
Hydraulic system | 25 gal
94.6 L |
Hydraulics | |
|---|---|
Type | closed center |
Capacity | 25 gal
94.6 L |
Pressure | 2250 psi
155.1 bar |
Valves | 2 to 4 |
Pump flow | 23 gpm
87.1 lpm |
Steering flow | 8 gpm
30.3 lpm |
Tractor hitch | |
|---|---|
Rear Type | III/II |
Rear lift | 6600 lbs
2993 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 108 inches
274 cm |
Weight | 13,495 lbs
6121 kg |
Front tire | 11.00-16 |
2WD Rear tire | 18.4-38 |
Full dimensions and tires ...  | |
1896 Serial Numbers | |
|---|---|
1984 | 9931800 |
1985 | 9938100 |
1986 | 9941573 |
1987 | 17895137 |
1988 | 17895512 |
1989 | 17895992 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 105 |
Battery volts | 12 |
References | |
|---|---|
 | |
Models 1896/2096 Foldable Tractor ROPS published by CaseIH | |
1985 Farm Equipment Buyer's Guide published by CaseIH |
 | |
|---|---|
