caseih 895
 | 1991 - 1994
95 Utility SeriesUtility tractor | 1991 - 1994 | 95 Utility Series | Utility tractor |
|---|---|---|---|---|
1991 - 1994 | ||||
95 Utility Series | ||||
Utility tractor | ||||
1991 - 1994 | |
|---|---|
95 Utility Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | CaseIH |
Utility tractor | |
Built in Doncaster, England | |
Original price was $27,500 in 1994 | |
CaseIH 895 Engine | |
|---|---|
Case IH 4.4L 4-cyl diesel | |
Engine details ...  |
CaseIH 895 Transmissions | |
|---|---|
8-speed partially synchronized | |
16-speed partial power shift | |
8-speed synchronized shuttle | |
16-speed creeper | |
Transmission details ...  |
CaseIH 895 Power | |
|---|---|
Engine (gross) | 84 hp
62.6 kW |
Engine (net) | 79 hp
58.9 kW |
PTO (claimed) | 72 hp
53.7 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Hydraulic wet disc brakes | |
Two-post ROPS. Cab optional with air-conditioning. |
Photos | |
|---|---|
 | |
CaseIH 895 photos...  |
Capacity | |
|---|---|
ROPS Fuel | 20 gal
75.7 L |
Cab Fuel | 29.5 gal
111.7 L |
Hydraulic system | 9 gal
34.1 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 9 gal
34.1 L |
Valves | 1 |
Pump flow | 15.8 gpm
59.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Rear lift | 3665 lbs
1662 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 |
| 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 88.7 inches
225 cm |
Weight | 6065 to 8023 pounds |
Front tire | 7.50-16 |
Rear tire | 16.9-24 |
Full dimensions and tires ...  | |
CaseIH 895 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
95 Series Tractors published in 1990, by CaseIH |
 | |
|---|---|
