caseih cs 150
 | 1997 - 2003
CS SeriesRow-Crop tractor | 1997 - 2003 | CS Series | Row-Crop tractor |
|---|---|---|---|---|
1997 - 2003 | ||||
CS Series | ||||
Row-Crop tractor | ||||
1997 - 2003 | |
|---|---|
CS Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | CaseIH |
Row-Crop tractor | |
Built in Saint Valentin, Austria | |
Variants | |
|---|---|
9145 | similar Steyr model |
CaseIH CS 150 Engine | |
|---|---|
Sisu 6.6L 6-cyl diesel | |
Fuel tank | 58.1 gal
219.9 L |
| 79.3 gal*Total capacity with optional 80 liter fuel tank.
300.2 L |
Engine details ...  | |
CaseIH CS 150 Transmissions | |
|---|---|
24-speed four-speed power shift | |
40-speed creeper | |
Transmission details ...  |
CaseIH CS 150 Power | |
|---|---|
Engine (net) | 143 hp
106.6 kW |
PTO (claimed) | 129.2 hp
96.3 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Wet disc brakes | |
Cab standard with air-conditioning. |
Photos | |
|---|---|
No photos of the CaseIH CS 150 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics | |
|---|---|
Pressure | 2683 psi
185.0 bar |
Pump flow | 21.1 gpm
79.9 lpm |
| 30.4 gpmOptOptional
115.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@2200 |
| 540E@1680 |
| 1000@2200 |
| 1000E@1600 |
Front PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 110.6 inches
280 cm |
Weight | 11651 lbs
5284 kg |
Front tire | 540/65R28 |
Rear tire | 650/65R38 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
CS110-CS150 published in 1998, by CaseIH | |
CS110 & CS150 published in 2000, by CaseIH |
 | |
|---|---|
