caseih farmall 70a
 | 2015 -
Farmall A SeriesUtility tractor | 2015 - | Farmall A Series | Utility tractor |
|---|---|---|---|---|
2015 - | ||||
Farmall A Series | ||||
Utility tractor | ||||
2015 - | |
|---|---|
Farmall A Series | |
Utility tractor |
Production | |
|---|---|
Manufacturer | CaseIH |
Utility tractor | |
Built in India | |
CaseIH Farmall 70A Engine | |
|---|---|
FPT 2.2L 3-cyl diesel | |
Fuel tank | 13 gal
49.2 L |
Engine details ...  | |
CaseIH Farmall 70A Transmission | |
|---|---|
8-speed mechanical shuttle | |
Transmission details ...  |
CaseIH Farmall 70A Power | |
|---|---|
Engine (gross) | 70 hp
52.2 kW |
PTO (claimed) | 62 hp
46.2 kW |
PTO (tested) | 63.99 hp
47.7 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Final drives | planetary |
Differential lock | mechanical rear |
Power steering | |
Wet disc brakes | |
Two-post folding ROPS. | |
Photos | |
|---|---|
No photos of the CaseIH Farmall 70A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics | |
|---|---|
Type | open center |
Rear valves | 1 or 2 |
Mid valves | 0 or 2 |
Pump flow | 11.9 gpm
45.0 lpm |
Steering flow | 5.5 gpm
20.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Rear lift (at 24"/610mm) | 2701 lbs
1225 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Engine RPM | 540@2575 |
| 540E@2016 |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 96.4 inches
244 cm |
4WD Wheelbase | 97.6 inches
247 cm |
Weight | 4442 to 5060 pounds |
Front tire | 7.5x16 |
2WD Rear tire | 13.6x28 |
Full dimensions and tires ...  | |
CaseIH Farmall 70A attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 75 |
Battery volts | 12 |
References | |
|---|---|
 | |
Utility Farmall A Series Tractors published in 2016, by CaseIH* | |
Utility Farmall A Series Tractors published in 2017, by CaseIH | |
Farmall Utility Series Tractors published in 2021, by CaseIH | |
*Publication contains known errors. |
 | |
|---|---|
