caseih farmall 90
 | 2008 - 2010
Farmall Utility SeriesUtility tractorTurk Tractor built | 2008 - 2010 | Farmall Utility Series | Utility tractor | Turk Tractor built |
|---|---|---|---|---|---|
2008 - 2010 | |||||
Farmall Utility Series | |||||
Utility tractor | |||||
Turk Tractor built | |||||
2008 - 2010 | |
|---|---|
Farmall Utility Series | |
Utility tractor | |
Turk Tractor built |
Production | |
|---|---|
Distributor | CaseIH |
Manufacturer | Turk Tractor |
Utility tractor | |
Built in Ankara, Turkey | |
CaseIH Farmall 90 Engine | |
|---|---|
FPT 4.5L 4-cyl diesel | |
Fuel tank | 23.8 gal
90.1 L |
Engine details ...  | |
CaseIH Farmall 90 Transmissions | |
|---|---|
12-speed mechanical shuttle | |
20-speed mechanical shuttle with creeper | |
Transmission details ...  |
CaseIH Farmall 90 Power | |
|---|---|
Engine (gross) | 84 hp
62.6 kW |
PTO (claimed) | 70 hp
52.2 kW |
Drawbar (tested) | 65.2 hp
48.6 kW |
PTO (tested) | 73.5 hp
54.8 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Hydraulic wet disc brakes | |
Flat deck platform with ROPS. Cab optional. | |
Photos | |
|---|---|
 | |
CaseIH Farmall 90 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2755 psi
190.0 bar |
Rear valves | 1 to 3 |
Pump flow | 13.6 gpm
51.5 lpm |
Total flow | 21.7 gpm
82.1 lpm |
Steering flow | 8.1 gpm
30.7 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position control and mechanical lower-link draft sensing |
Rear lift (at 24"/610mm) | 5025 lbs
2279 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | mechanical dry clutch |
Rear PTO Type | 540 (1.375) |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 91 inches
231 cm |
4WD Wheelbase | 87 inches
220 cm |
Weight | 5702 to 6915 pounds |
Full dimensions and tires ...  | |
CaseIH Farmall 90 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 85 |
Battery CCA | 800 |
Battery volts | 12 |
References | |
|---|---|
 | |
Farmall Series Utility Tractors published in 2008, by CaseIH |
 | |
|---|---|
