caseih jx95
 | 2002 - 2009
Model year 2002-20032003-2009
JX SeriesUtility tractorTurk Tractor built | 2002 - 2009 | Model year 2002-20032003-2009 | JX Series | Utility tractor | Turk Tractor built |
|---|---|---|---|---|---|---|
2002 - 2009 | ||||||
Model year 2002-20032003-2009 | ||||||
JX Series | ||||||
Utility tractor | ||||||
Turk Tractor built | ||||||
2002 - 2009 | |
|---|---|
Model year 2002-20032003-2009 | |
JX Series | |
Utility tractor | |
Turk Tractor built |
Production | |
|---|---|
Distributor | CaseIH |
Manufacturer | Turk Tractor |
Utility tractor | |
Built in Turkey | |
Variants | |
|---|---|
JX95 | utility |
JX95HC | high-crop |
CaseIH JX95 Engine | |
|---|---|
Iveco 3.9L 4-cyl diesel | |
Fuel tank | 24.3 gal
92.0 L |
Engine details ...  | |
CaseIH JX95 Transmissions | |
|---|---|
12-speed mechanical shuttle | |
20-speed creeper | |
Transmission details ...  |
CaseIH JX95 Power | |
|---|---|
Engine (gross) | 93 hp
69.4 kW |
PTO (claimed) | 80 hp
59.7 kW |
Drawbar (tested) | 66.3 hp
49.4 kW |
PTO (tested) | 83.8 hp
62.5 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | mechanical rear |
Steering | hydrostatic power |
Independent wet disc brakes | |
Two-post ROPS. Cab optional. | |
Photos | |
|---|---|
No photos of the CaseIH JX95 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics | |
|---|---|
Type | open center |
Valves | 3 |
Pump flow | 10.6 gpm
40.1 lpm |
| 13.6 gpm*Optional, standard in USA
51.5 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Rear lift | 7718 lbs*Advertised. 3820 lbs actual lift during testing
3500 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/540E |
| 540/1000 OptOptional |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 94 inches
238 cm |
4WD Wheelbase | 91.8 inches
233 cm |
Weight | 6790 to 7615 pounds |
Full dimensions and tires ...  | |
CaseIH JX95 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
JX95 Serial Number Location | |
|---|---|
 | |
Serial number plate located below the steering column. |
JX95 Serial Numbers | |
|---|---|
2003 | HFJ000001 |
2004 | HFJ013982 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
 | |
|---|---|
