caterpillar d6
 | 1941 - 1947
Agricultural Crawler tractor | 1941 - 1947 | Agricultural Crawler tractor |
|---|---|---|---|
1941 - 1947 | |||
Agricultural Crawler tractor | |||
1941 - 1947 | |
|---|---|
Agricultural Crawler tractor |
Production | |
|---|---|
Manufacturer | Caterpillar |
Agricultural Crawler tractor | |
Built in Peoria, Illinois, USA | |
Caterpillar D6 Engines | |
|---|---|
Caterpillar 7.7L 6-cyl diesel | |
Caterpillar 8.6L 6-cyl diesel | |
Fuel tank | 48 gal
181.7 L |
Engine details ...  | |
Caterpillar D6 Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Caterpillar D6 Power | |
|---|---|
Drawbar (tested) | 74.82 hp
55.8 kW |
Belt (tested) | 92.52 hp
69.0 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Drive | crawler |
Steering | manual clutch |
Contracting band brakes | |
Open operator station. | |
Photos | |
|---|---|
 | |
Caterpillar D6 photos...  |
Dimensions & Tracks | |
|---|---|
Wheelbase | 85.625 inches
217 cm |
Weight | 16695 to 17330 pounds |
16-inch tracks | |
Full dimensions and tracks ...  | |
Belt Pulley | |
|---|---|
Diameter | 13 inches
33 cm |
Width | 13 inches
33 cm |
RPM | 913 |
Speed | 3200 ft/min
975.36 meters/min |
References | |
|---|---|
 | |
Product Line published in 1953, by Caterpillar | |
Farming on the contour published in 1954, by Caterpillar |
 | |
|---|---|
