challenger mt535e
 | 2015 - 2020
MT500E SeriesRow-Crop tractor | 2015 - 2020 | MT500E Series | Row-Crop tractor |
|---|---|---|---|---|
2015 - 2020 | ||||
MT500E Series | ||||
Row-Crop tractor | ||||
2015 - 2020 | |
|---|---|
MT500E Series | |
Row-Crop tractor |
Tractor Tests | |
|---|---|
OECD 2992: diesel AutoPower VI 4WD | |
OECD 2989: diesel TechStar CVT 4WD |
OCED Tractor Test 2992 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2992 | |
|---|---|
Diesel AutoPower VI 4WD
May 2016 - August 2016,
Link: OCED Tractor Test 2992 file | |
PTO performance | |
Max power | 150.2 hp
112.0 kW |
Fuel use | 8.1 gal/hour
30.7 l/hour |
Power at rated engine speed | 141.1 hp
105.2 kW |
Fuel use | 8.1 gal/hour
30.7 l/hour |
Power at rated PTO speed | 149.4 hp
111.4 kW |
Fuel use | 8.4 gal/hour
31.8 l/hour |
Drawbar performance | |
Max power | 125.1 hp
93.3 kW |
Fuel use | 8.1 gal/hour
30.7 l/hour |
Gear 3B used for power test. | |
Max pull | 13625 lbs
6180 kg |
Gear 1F used for pull test. | |
OCED Tractor Test 2989 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2989 | |
|---|---|
Diesel TechStar CVT 4WD
July 2016 - August 2016,
Link: OCED Tractor Test 2989 file | |
PTO performance | |
Max power | 154.9 hp
115.5 kW |
Fuel use | 8.8 gal/hour
33.3 l/hour |
Power at rated engine speed | 147.5 hp
110.0 kW |
Fuel use | 8.6 gal/hour
32.6 l/hour |
Power at rated PTO speed | 152.2 hp
113.5 kW |
Fuel use | 8.5 gal/hour
32.2 l/hour |
Drawbar performance | |
Max power | 121.9 hp
90.9 kW |
Fuel use | 8.9 gal/hour
33.7 l/hour |
Pull at 10.1KPH | |
Max pull | 15465 lbs
7014 kg |
Pull at 4.14KPH | |
