challenger mt755c
 | 2009 - 2011
MT700C SeriesAgricultural Crawler tractor | 2009 - 2011 | MT700C Series | Agricultural Crawler tractor |
|---|---|---|---|---|
2009 - 2011 | ||||
MT700C Series | ||||
Agricultural Crawler tractor | ||||
2009 - 2011 | |
|---|---|
MT700C Series | |
Agricultural Crawler tractor |
Production | |
|---|---|
Manufacturer | Challenger (a part of AGCO) |
Agricultural Crawler tractor | |
Built in Jackson, Minnesota, USA | |
Original price was $228,190 in 2009 | |
Challenger MT755C Engine | |
|---|---|
Caterpillar 8.8L 6-cyl | |
Fuel tank | 118 gal
446.6 L |
| 208 galOptOptional
787.3 L |
Engine details ...  | |
Challenger MT755C Transmission | |
|---|---|
16-speed full power shift | |
Transmission details ...  |
Challenger MT755C Power | |
|---|---|
Engine (gross) | 301 hp
224.5 kW |
PTO (claimed) | 245 hp
182.7 kW |
Drawbar (tested) | 213.58 hp
159.3 kW |
PTO (tested) | 315.95 hp
235.6 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Drive | crawler |
Steering | speed sensitive differential |
Trailer brakes | hydraulic OptOptional |
Cab standard with air-conditioning. | |
Hydraulics | |
|---|---|
Type | closed center pressure-flow compensated |
Pressure | 2900 psi
200.0 bar |
Valves | 4 to 6 |
Pump flow | 36 gpm
136.3 lpm |
Total flow | 43.5 gpm
164.6 lpm |
| 59 gpmOptOptional
223.3 lpm |
Tractor hitch | |
|---|---|
Rear Type | III/IIIN |
Rear lift | 16,000 lbs
7257 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 1000 (1.75) |
Dimensions & Tracks | |
|---|---|
Wheelbase | 96 inches
243 cm |
Weight | 31,075 lbs
14095 kg |
Tracks | |
Full dimensions and tracks ...  | |
MT755C Serial Number Location | |
|---|---|
 | |
Serial number plate on the main front left side of the tractor frame. |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 185 |
Batteries | 2 |
Battery CCA | 1000 |
Battery volts | 12 |
