cletrac hg
 | 1939 - 1951
Agricultural Crawler tractor | 1939 - 1951 | Agricultural Crawler tractor |
|---|---|---|---|
1939 - 1951 | |||
Agricultural Crawler tractor | |||
1939 - 1951 | |
|---|---|
Agricultural Crawler tractor |
Production | |
|---|---|
Manufacturer | Cletrac (a part of Oliver) |
Agricultural Crawler tractor | |
Built in Cleveland, Ohio, USA | |
Total built | 29,930 |
Cletrac HG Engines | |
|---|---|
Hercules 2.2L 4-cyl gasoline | |
Hercules 1.9L 4-cyl gasoline | |
Hercules 2.0L 4-cyl gasoline | |
Fuel tank | 12 gal
45.4 L |
Engine details ...  | |
Cletrac HG Transmission | |
|---|---|
3-speed gear | |
Transmission details ...  |
Cletrac HG Power | |
|---|---|
Drawbar (claimed) | 22 hp
16.4 kW |
Belt (claimed) | 16 hp
11.9 kW |
Drawbar (tested) | 21.3 hp
15.9 kW |
Belt (tested) | 25.3 hp
18.9 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Drive | crawler |
Open operator station. | |
Photos | |
|---|---|
 | |
Cletrac HG photos...  |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540 (1.375) |
Dimensions & Tracks | |
|---|---|
Weight | 3125 to 3496 pounds |
6-inch tracks | |
Full dimensions and tracks ...  | |
HG Serial Numbers | |
|---|---|
1939 | 1GA000 |
1940 | 2GA884 |
1941 | 5GA024 |
1942 | 7GA484 |
1943 | 8GA702 |
1944 | 9GA630 |
1945 | 13GA490 |
1946 | 19GA994 |
1947 | 25GA240 |
1948 | 33GA146 |
1949 | 41GA896 |
1950 | 48GA428 |
1951 | 55GA430 |
FAQ: How to read a serial number table. | |
References | |
|---|---|
 | |
HG - Tru-Traction for the Farmer published in 1941, by Cletrac | |
HG Tractors published in 1948, by Cletrac |
 | |
|---|---|
