co op e5
 | Row-Crop tractor | Row-Crop tractor |
|---|---|---|
Row-Crop tractor | ||
Row-Crop tractor |
|---|
Note: the CO-OP model E5 is the same as the Cockshutt 50. The following data is from the 50 listing. |
|---|
Production | |
|---|---|
Manufacturer | CO-OP |
Row-Crop tractor | |
Built in Brantford, Ontario, Canada | |
Total built | 3,974 |
Original price | $4,100 (1957) |
CO-OP E5 Engines | |
|---|---|
Buda 4.5L 6-cyl gasoline | |
Buda 4.5L 6-cyl diesel | |
Fuel tank | 21 gal
79.5 L |
Engine details ...  | |
CO-OP E5 Transmission | |
|---|---|
6-speed unsynchronized gear | |
Transmission details ...  |
CO-OP E5 Power | |
|---|---|
Drawbar (claimed) | 39 hp
29.1 kW |
Belt (claimed) | 49 hp
36.5 kW |
Plows | 4-5 |
Drawbar (tested) | 51.59 hp
38.5 kW |
Belt (tested) | 55.56 hp
41.4 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two-wheel drive | |
Independent mechanical disc brakes | |
Open operator station. |
Photos | |
|---|---|
No photos of the CO-OP E5 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 |
Dimensions & Tires | |
|---|---|
Wheelbase | 86.5 inches
219 cm |
Weight | 6041 to 6163 pounds |
Front tire | 7.50x16 |
Rear tire | 14.00x34 |
Full dimensions and tires ...  | |
E5 Serial Numbers | |
|---|---|
Location: | Serial number stamped into the top of the Cockshutt 50 tractor frame on the left side. |
1953 | 101 |
1954 | 1750 |
1955 | 10001 |
1956 | 20001 |
1957 | 30001 |
1958 | 40001 |
Final | 40257 |
FAQ: How to read a serial number table. | |
 | |
|---|---|
