deutz fahr dx 120
 | 1981 - 1983
DX SeriesRow-Crop tractor | 1981 - 1983 | DX Series | Row-Crop tractor |
|---|---|---|---|---|
1981 - 1983 | ||||
DX Series | ||||
Row-Crop tractor | ||||
1981 - 1983 | |
|---|---|
DX Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Deutz-Fahr |
Row-Crop tractor | |
Deutz-Fahr DX 120 Engine | |
|---|---|
Deutz 6.1L 6-cyl diesel | |
Fuel tank | 31.7 gal
120.0 L |
Engine details ...  | |
Deutz-Fahr DX 120 Transmission | |
|---|---|
15-speed synchronized | |
Transmission details ...  |
Deutz-Fahr DX 120 Power | |
|---|---|
PTO (claimed) | 110 hp
82.0 kW |
Drawbar (tested) | 92.86 hp
69.2 kW |
PTO (tested) | 111.29 hp
83.0 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Final drives | bull gear |
Power steering | |
Hydraulic disc brakes | |
Cab standard with air-conditioning. | |
Photos | |
|---|---|
 | |
Deutz-Fahr DX 120 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Pump flow | 14.8 gpm
56.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Rear lift | 11466 lbs
5200 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 105.8 inches
268 cm |
Weight | 10804 lbs
4900 kg |
Front tire | 14.9-24 |
Rear tire | 18.4-38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
DX90-DX120-Dx130-DX140-DX160 published in 1980, by Deutz-Fahr |
