farmall 544
 | 1968 - 1973
Row-Crop tractor | 1968 - 1973 | Row-Crop tractor |
|---|---|---|---|
1968 - 1973 | |||
Row-Crop tractor | |||
1968 - 1973 | |
|---|---|
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Farmall (a part of International Harvester) |
Row-Crop tractor | |
Built in Rock Island, Illinois, USA | |
Variants | |
|---|---|
IH 544 | utility tractor |
2544 | industrial tractor |
Farmall 544 Engines | |
|---|---|
International Harvester 3.9L 4-cyl diesel | |
International Harvester 3.3L 4-cyl gasoline | |
Diesel Fuel tank | 23 gal
87.1 L |
Gasoline Fuel tank | 33 gal
124.9 L |
Engine details ...  | |
Farmall 544 Transmissions | |
|---|---|
5-speed gear | |
10-speed two-speed power shift | |
5-speed shuttle | |
hydrostatic | |
Transmission details ...  |
Farmall 544 Power | |
|---|---|
Drawbar (claimed) | 45.5 hp
33.9 kW |
PTO (claimed) | 52 hp
38.8 kW |
Plows | 4 (16-inch) |
Drawbar (tested) | 44.74 hp
33.4 kW |
PTO (tested) | 55.52 hp
41.4 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two-wheel drive | |
Power steering | |
Independent mechanical disc brakes | |
Open operator station. Cab optional with heater. |
Photos | |
|---|---|
 | |
Farmall 544 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Valves | 0 to 2 |
Tractor hitch | |
|---|---|
Rear Type | II/I |
Type | IH Fast Hitch |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 90 inches
228 cm |
Weight | 6100 to 7195 pounds |
Front tire | 6.00-16 |
Rear tire | 13.6-38 |
Full dimensions and tires ...  | |
Farmall 544 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
544 Serial Number Location | |
|---|---|
 | |
Serial number plate on the right side of the tractor, on the clutch housing. |
544 Serial Numbers | |
|---|---|
1968 | 10250 |
1969 | 12541 |
1970 | 13585 |
1971 | 14507 |
1972 | 15262 |
1973 | 15738 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Charging system | alternator |
Charging amps | 55 |
Gasoline Batteries | 1 |
Diesel Batteries | 2 |
Gasoline Battery volts | 12 |
Diesel Battery volts | 6 |
Gasoline Battery AH | 50 |
Diesel Battery AH | 135 |
References | |
|---|---|
 | |
Farm Loaders published in 1970, by International Harvester | |
Spring 1968 Buyer's Guide published by International Harvester | |
Summer-Fall 1968 Buyer's Guide published by International Harvester | |
World Wide Farm Equipment Buyer's Guide published in 1968, by International Harvester* | |
Spring 1969 Buyer's Guide published by International Harvester | |
Spring 1970 Buyer's Guide published by International Harvester | |
Spring 1971 Buyer's Guide published by International Harvester | |
Farm Equipment Reference Catalog published in 1968, by International Harvester | |
*Publication contains known errors. |
