fendt farmer 412 vario
 | 2001 - 2006
Model year 2001-20042004-2006
Farmer 400 SeriesRow-Crop tractor | 2001 - 2006 | Model year 2001-20042004-2006 | Farmer 400 Series | Row-Crop tractor |
|---|---|---|---|---|---|
2001 - 2006 | |||||
Model year 2001-20042004-2006 | |||||
Farmer 400 Series | |||||
Row-Crop tractor | |||||
2001 - 2006 | |
|---|---|
Model year 2001-20042004-2006 | |
Farmer 400 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Fendt |
Row-Crop tractor | |
Fendt Farmer 412 Vario Engine | |
|---|---|
Deutz 3.8L 4-cyl diesel | |
Fuel tank | 43.6 gal
165.0 L |
Engine details ...  | |
Fendt Farmer 412 Vario Transmission | |
|---|---|
continuously variable transmission | |
Transmission details ...  |
Fendt Farmer 412 Vario Power | |
|---|---|
Engine | 120 hp
89.5 kW |
Drawbar (tested) | 85.15 hp
63.5 kW |
PTO (tested) | 115.9 hp
86.4 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard with heater. Air-conditioning optional. |
Photos | |
|---|---|
 | |
Fendt Farmer 412 Vario photos...  |
Hydraulics | |
|---|---|
Pump flow | 19.8 gpm
74.9 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift | 14482 lbs
6569 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/750/1000 |
Engine RPM | 540@1932 |
| 1000@1937 |
Front PTO | independent OptOptional |
Front PTO Type | 540 |
| 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 95.2 inches
241 cm |
Weight | 11552 lbs
5239 kg |
Front tire | 540/65R24 |
Rear tire | 600/65R38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 143 |
Battery volts | 12 |
Battery AH | 90 |
References | |
|---|---|
 | |
Farmer 400 Vario 409 410 411 412 published in 2001, by Fendt | |
412 Specifications published in 2001, by Fendt |
