fiat 880 5
 | 1980 - 1984 | 1980 - 1984 |
|---|---|---|
1980 - 1984 | ||
1980 - 1984 |
|---|
Production | |
|---|---|
Manufacturer | Fiat |
Fiat 880/5 Engine | |
|---|---|
Fiat 4.6L 5-cyl diesel | |
Fuel tank | 30.6 gal
115.8 L |
Engine details ...  | |
Fiat 880/5 Transmissions | |
|---|---|
12-speed synchronized | |
16-speed creeper | |
Transmission details ...  |
Fiat 880/5 Power | |
|---|---|
Engine | 88 hp
65.6 kW |
PTO (claimed) | 78 hp (540rpm)
58.2 kW |
| 84 hp (1000rpm)
62.6 kW |
Drawbar (tested) | 67.78 hp
50.5 kW |
PTO (tested) | 81.32 hp
60.6 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Final drives | planetary |
Differential lock | mechanical rear |
Power steering | |
Hydraulic wet disc brakes | |
Open operator station. Four-post ROPS and cab available. | |
Hydraulics | |
|---|---|
Pump flow | 14.8 gpm
56.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Rear lift | 6262 lbs
2840 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Engine RPM | 540@2124 |
| 1000@2400 |
Dimensions & Tires | |
|---|---|
Wheelbase | 96.5 inches
245 cm |
Weight | 6734 to 7594 pounds |
Front tire | 7.50-20 |
2WD Rear tire | 18.4-34 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
Battery volts | 12 |
