fiat 980
 | 1979 - 1984 | 1979 - 1984 |
|---|---|---|
1979 - 1984 | ||
1979 - 1984 |
|---|
Production | |
|---|---|
Manufacturer | Fiat |
Fiat 980 Engine | |
|---|---|
Fiat 5.2L 6-cyl diesel | |
Fuel tank | 30.6 gal
115.8 L |
Engine details ...  | |
Fiat 980 Transmissions | |
|---|---|
12-speed synchronized | |
16-speed creeper | |
Transmission details ...  |
Fiat 980 Power | |
|---|---|
Engine | 98 hp
73.1 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Wet disc brakes | |
Open operator station. ROPS and cab available. |
Photos | |
|---|---|
 | |
Fiat 980 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Pump flow | 10.9 gpm
41.3 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and draft control |
Rear lift | 7056 lbs
3200 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@2124 |
| 1000@2400 |
Dimensions & Tires | |
|---|---|
Wheelbase | 100 inches
254 cm |
Weight | 7628 to 8289 pounds |
Front tire | 7.50-20 |
2WD 12.4/11-28:16.9/14-38 4WD} Rear tire | 16.9/14-38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
Battery volts | 12 |
