ford 1910
 | 1983 - 1986
Ten Compact SeriesCompact Utility tractorShibaura built | 1983 - 1986 | Ten Compact Series | Compact Utility tractor | Shibaura built |
|---|---|---|---|---|---|
1983 - 1986 | |||||
Ten Compact Series | |||||
Compact Utility tractor | |||||
Shibaura built | |||||
1983 - 1986 | |
|---|---|
Ten Compact Series | |
Compact Utility tractor | |
Shibaura built |
Production | |
|---|---|
Distributor | Ford |
Manufacturer | Shibaura |
Compact Utility tractor | |
Built in Japan | |
Original price was $10,000 in 1986 | |
Ford 1910 Engine | |
|---|---|
Shibaura 1.7L 3-cyl diesel | |
Engine details ...  |
Ford 1910 Transmissions | |
|---|---|
12-speed unsynchronized gear | |
12-speed partially synchronized | |
Transmission details ...  |
Ford 1910 Power | |
|---|---|
Engine | 32 hp
23.9 kW |
PTO (claimed) | 28.5 hp
21.3 kW |
Drawbar (tested) | 24.76 hp
18.5 kW |
PTO (tested) | 28.60 hp
21.3 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Final drives | spur gear |
Differential lock | mechanical rear |
Steering | manual |
| power (4WD) |
Differential mechanical drum brakes | |
Two-post fixed ROPS. | |
Photos | |
|---|---|
 | |
Ford 1910 photos...  |
Capacity | |
|---|---|
Fuel | 9.2 gal
34.8 L |
Hydraulic system | 7.4 gal
28.0 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 7.4 gal
28.0 L |
Pressure | 2133 psi
147.1 bar |
Pump flow | 5.1 gpm
19.3 lpm |
Total flow | 8.6 gpm
32.6 lpm |
Steering flow | 3.5 gpm
13.2 lpm |
Steering press. | 1000 psi
69.0 bar |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position control |
| draft control OptOptional |
Rear lift (at ends) | 3813 lbs
1729 kg |
Rear lift (at 24"/610mm) | 1584 lbs
718 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | live |
Rear PTO Type | 540 (1.375) |
Engine RPM | 540@2456 |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 66.3 inches
168 cm |
4WD Wheelbase | 66.9 inches
169 cm |
Weight | 2980 to 3246 pounds |
Front tire | 5.50-16 |
2WD Rear tire | 13.6-24 |
Full dimensions and tires ...  | |
Ford 1910 attachments | |
|---|---|
60" mid-mount mower deck | |
snowblower | |
front-end loader | |
backhoe | |
Attachment details ...  |
1910 Serial Number Location | |
|---|---|
 | |
Serial number plate on the left side of the Ford 1910, near the clutch pedal. |
1910 Serial Numbers | |
|---|---|
1983 | UP0001 |
1984 | UP01089 |
1985 | UP04638 |
1986 | UP08193 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 35 |
Charging volts | 12 |
Battery volts | 12 |
Battery AH | 100 |
References | |
|---|---|
 | |
Ford Shop Manual by Peter Letourneau | |
Farm Loaders published in 1988, by Ford | |
1000 Series Tractors published in 1985, by Ford | |
1000 Series Tractors published in 1987, by Ford | |
Salesman's Reference published in 1986, by Ford | |
Sales Reference Guide published in 1986, by Ford |
