gravely lawn tractors 14 g
 | 1992 - 2000
Model year 1992-19981999-2000
Professional G SeriesGarden tractor | 1992 - 2000 | Model year 1992-19981999-2000 | Professional G Series | Garden tractor |
|---|---|---|---|---|---|
1992 - 2000 | |||||
Model year 1992-19981999-2000 | |||||
Professional G Series | |||||
Garden tractor | |||||
1992 - 2000 | |
|---|---|
Model year 1992-19981999-2000 | |
Professional G Series | |
Garden tractor |
Production | |
|---|---|
Manufacturer | Gravely |
Garden tractor | |
Gravely 14-G Engine | |
|---|---|
14HP Kohler 398cc 1-cyl gasoline | |
Fuel tank | 5.3 gal
20.1 L |
Engine details ...  | |
Gravely 14-G Transmission | |
|---|---|
8-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Mechanical band brakes | |
Open operator station. |
Photos | |
|---|---|
 | |
Gravely 14-G photos...  |
Dimensions & Tires | |
|---|---|
Wheelbase | 52.3 inches
132 cm |
Weight | 853 lbs
386 kg |
Front tire | 16x6.50-8 |
Rear tire | 23x8.50-12 |
Full dimensions and tires ...  | |
Gravely 14-G attachments | |
|---|---|
40" mid-mount mower deck | |
50" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 15 |
Battery volts | 12 |
Battery AH | 42 |
Battery Group | 22F |
References | |
|---|---|
 | |
Riding Tractors published in 1991, by Gravely | |
Operator's Manual G Series (53213) published in 1992 | |
Service Manual Professional-G Series (26793B) |
