gravely lawn tractors 7173 h
 | 1986
Garden tractor | 1986 | Garden tractor |
|---|---|---|---|
1986 | |||
Garden tractor | |||
1986 | |
|---|---|
Garden tractor |
Production | |
|---|---|
Manufacturer | Gravely (a part of Ariens) |
Garden tractor | |
Gravely 7173-H Engine | |
|---|---|
17HP Kohler 2-cyl gasoline | |
Fuel tank | 4.5 gal
17.0 L |
Engine details ...  | |
Gravely 7173-H Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Tractor hitch | |
|---|---|
Rear Type | 0 OptOptional |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 48.5 inches
123 cm |
Weight | 826 to 870 pounds |
Front tire | 16x6.50-8 |
Rear tire | 23x10.50-12 |
Full dimensions and tires ...  | |
Gravely 7173-H attachments | |
|---|---|
48" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 15 |
Battery volts | 12 |
References | |
|---|---|
 | |
Riding Tractors published in 1986, by Gravely |
