international harvester 1086b
 | 1981 - 1982
86B SeriesRow-Crop tractor | 1981 - 1982 | 86B Series | Row-Crop tractor |
|---|---|---|---|---|
1981 - 1982 | ||||
86B Series | ||||
Row-Crop tractor | ||||
1981 - 1982 | |
|---|---|
86B Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | International Harvester |
Row-Crop tractor | |
Built in Geelong, Australia | |
Total built | 164 |
International Harvester 1086B Engine | |
|---|---|
International Harvester 6.8L 6-cyl diesel | |
Engine details ...  |
International Harvester 1086B Transmission | |
|---|---|
16-speed Torque Amplifier | |
Transmission details ...  |
International Harvester 1086B Power | |
|---|---|
Engine | 148 hp
110.4 kW |
PTO (claimed) | 98 hp
73.1 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | electro-hydraulic rear |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard. | |
Hydraulics | |
|---|---|
Type | open center |
Tractor hitch | |
|---|---|
Rear Type | III/II |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@2100 |
| 1000@2100 |
Dimensions & Tires | |
|---|---|
Weight | 13117 lbs
5949 kg |
Front tire | 11.00-16 |
Rear tire | 24.5-32 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
International Harvester Australia: Geelong Works by Sarah Tomac* | |
International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick | |
Technical Annual published in 1983, by Power Farming | |
*Publication contains known errors. |
